Eaton EC330膠管 2 Wire Braid Hose
EC330膠管, 它可廣泛用于油氣、工程機械、農機、高壓系統(tǒng)等。
EC330可與寧波一體式接頭（xxxx1YT-xx-xxZ）匹配，共6/8/10/12四個規(guī)格。工作壓力性能符合EN856 4SP的要求，在彎曲半徑方面超越4SP標準。
Eaton EC330 2 Wire Braid Hose膠管
資料下載PDF Catalog
# Part Number |
DN |
Hose I.D. |
Hose O.D. |
Maximum Working Pressure |
Minimum Burst Pressure |
Minimum Bend Radius |
Weight |
|
|
mm |
in |
mm |
in |
bar |
psi |
bar |
psi |
mm |
in |
kg/m |
lb/ft |
EC330-06 |
10 |
9,5 |
0.38 |
19,7 |
0.78 |
445 |
6450 |
1780 |
25800 |
120 |
4.72 |
0,81 |
0.54 |
EC330-08 |
12 |
12,7 |
0.50 |
22,9 |
0.90 |
415 |
6000 |
1660 |
24000 |
160 |
6.30 |
0,94 |
0.63 |
EC330-10 |
16 |
15,9 |
0.62 |
26,5 |
1.04 |
350 |
5100 |
1400 |
20400 |
210 |
8.27 |
1,13 |
0.76 |
EC330-12 |
19 |
19,0 |
0.75 |
30,0 |
1.18 |
350 |
5100 |
1400 |
20400 |
260 |
10.24 |
1,49 |
1.00 |
Hose |
WP (Bar) |
MBR(mm) |
4SP hose MBR(mm) |
Fitting Type |
EC330-06 |
445 |
120 |
180 |
Winner One-Piece xxxx1YT-xx-xxZ |
EC330-08 |
415 |
160 |
230 |
EC330-10 |
350 |
210 |
250 |
EC330-12 |
350 |
260 |
300 |
Construction Operating Temperature Range Agency Listings Application
Inner Tube: -40°C to + 100°C MSHA approved High pressure hydraulic systems
Synthetic Rubber (-40°F to + 212°F) Petroleum & Water-based fluids
Reinforcement: Construction Equipment
3 Wire Braid
Cover:
Black Synthetic Rubber
Ink Transfer Layline
|
