Parker Legris樂可利工業用球閥
Legris Industrail Ball Valves | LEGRIS Ball Valves | Axial Valves - legris

Legris樂可利球閥可提供如下功能:

- 手動實現開啟和關閉一個回路.
- 通過氣控或電控來開啟和關閉一個回路, 如軸閥.
- 調節流量大小: 如針閥

銅質球閥-低 / 中壓力范圍

樂可利銅質球閥適用于中低壓場合，可用手動實現開啟和關閉，從而達到控制壓縮空氣和其他流體的功能．具有多種型式供選擇：直通，三通，帶鎖型等．工作壓力從１２到40u bar；根據不同的款型，工作溫度可從-20°到 +130°C　

Parker Legris Industrial Valves Ball Valves Needle Valves Ground Plug Shutoff Valves/Drain Cocks

低/中壓不銹鋼球閥

樂可利不銹鋼球閥適用于惡劣的流體和腐蝕性的工作環境，具有優異的耐壓和耐溫性能．根據不同款型，工作壓力從25至140bar；工作溫度從-10°到 +180°C．該產品有多種材質供選擇：AISI 316, 304L 和 303L；有FKM密封圈和PTFE密封墊供選擇．

Parker派克聚丙烯球閥通過內置的 LIQUIfit，TrueSeal 和插管式連接，耐腐蝕能力使其成為水過濾裝置，咖啡和飲料機以及各種其他流體應用的選擇。派克的聚丙烯球閥耐腐蝕能力使其成為水過濾裝置，咖啡和飲料機以及各種其他流體應用的選擇。派克的聚丙烯球閥通過內置的 LIQUIfit，TrueSeal 和插管式連接節省成本，無需二次配件。緊湊的設計易于安裝，節省空間并易于維護。聚丙烯球閥符合所有的美國 FDA 和 NSF-51 要求，以保證其能夠與食品接觸。

Parker's polypropylene ball valves corrosion resistant design make them ideal for water filtration units, coffee and beverage machines and various other fluid applications. Parker's polypropylene ball valves save cost with built-in LIQUIfit, TrueSeal and Par-Barb connections eliminating the need for a secondary fitting. The compact design allows for easy assembly and access where space is at a premium. Polypropylene ball valves meets all FDA and NSF-51 requirements for food contact.

MINI-BALL VALVES

Legris mini-ball valves enable in-line opening and closing of a pneumatic circuit. Compact and light weight, they are suited to all types of installation.

BALL VALVES LIQUIFIT®

This range of valves offers an innovative solution in the treatment of water and the handling of beverages while protecting health. These compact and reliable valves offer perfect sealing and excellent cleanliness.Nominal pressure: 10 bar, temperatures: -15°C to +100°C.

針閥

樂可利針閥用于開啟和關閉回路，同時可以精確地控制流量，有直通式和直角式．工作壓力為：120 bar；工作溫度從-20°到+100°C．材質：銅鍍鎳，表面噴沙處理． STAINLESS STEEL NEEDLE VALVE Excellent chemical resitance to aggressive fluids and environments. Good
resistance to pressure. PTFE O-rings.


先導閥

樂可利軸閥用于通過氣控或電控遠距離實現開啟和關閉的功能．與一般的執行器比較，樂可利軸閥外形更緊湊，可節省大約５０％的空間．工作壓力為１０bar；根據不同的型式，工作溫度：-20°到，+120°C (EPDM密封圈)或 +135°C（FKM密封圈）

0402 - BALL VALVE DOUBLE FEMALE
Ball valve for opening and closing fluid circuits with a simple quarter turn of the handle.
Universal series, available from 1/8" to 2" parallel thread.

0401 - BALL VALVE MALE FEMALE0401 - BALL VALVE MALE FEMALE
Ball valve for opening and closing fluid circuits with a simple quarter turn of the handle.
Universal series, available from 1/8" to 1"1/4 parallel thread.

0400 - BALL VALVE DOUBLE MALE0400 - BALL VALVE DOUBLE MALE
Ball valve for opening and closing fluid circuits with a simple quarter turn of the handle.
Universal series, available from 1/8" to 3/4" parallel thread.

0411 - VALVE WITH 2 COUPLINGS FOR USE WITH STEEL TUBE0411 - VALVE WITH 2 COUPLINGS FOR USE WITH STEEL TUBE
Vented ball valve for opening and closing circuits with steel tubes.
Universal series, available from 6 mm to 12 mm parallel thread.

0414 - VALVE WITH 2 COUPLINGS WITH DOUBLE TAPER RINGS0414 - VALVE WITH 2 COUPLINGS WITH DOUBLE TAPER RINGS
In-line ball valve with two couplings fitted with double taper rings for steel or thermoplastic tubes.
Universal series, available from 6 mm to 12 mm parallel thread.

0446 - BALL VALVE DOUBLE FEMALE PANEL MOUNTED0446 - BALL VALVE DOUBLE FEMALE PANEL MOUNTED
Panel mountable in-line ball valve for opeing and closing fluid systems.
Universal series, available from 1/8" to 1/2" parallel thread.

6402 - DOUBLE FEMALE BALL VALVE FOR SCREW FIXING6402 - DOUBLE FEMALE BALL VALVE FOR SCREW FIXING
Mountable ball valve for opening and closing fluid systems.
Universal series, available from 1/8" to 1" parallel thread.

6401 - MALE AND FEMALE BALL VALVE FOR SCREW FIXING6401 - MALE AND FEMALE BALL VALVE FOR SCREW FIXING
Mountable ball valve for opening and closing fluid systems with optimum sealing due to "O" rings.
Universal series, available from 1/8" to 1/2" parallel thread.

0489 - IN-LINE VENTED BALL VALVE DOUBLE FEMALE BSPP0489 - IN-LINE VENTED BALL VALVE DOUBLE FEMALE BSPP
Double female BSPP valve, with threaded exhaust.
Universal series, available from 1/4" to 1" parallel thread.

0449 - VENTED BALL VALVE DBLE FEMALE PANEL MOUNTABLE0449 - VENTED BALL VALVE DBLE FEMALE PANEL MOUNTABLE
Double female BSPP valve, panel mountable, with threaded exhaust.
Universal series, available from 1/4" to 1/2" parallel thread.

0469 - DOUBLE FEMALE VENTED BSPP BALL VALVE0469 - DOUBLE FEMALE VENTED BSPP BALL VALVE
In-line vented ball valve.
Universal series, available from 1/8" to 1" parallel thread.

4402 - HIGH PRESSURE BALL VALVE, DOUBLE FEMALE4402 - HIGH PRESSURE BALL VALVE, DOUBLE FEMALEOffers excellent pressure resistance.
0472 - BALL VALVE WITH RIGHT ANGLED FLOW, DOUBLE FEMALE0472 - BALL VALVE WITH RIGHT ANGLED FLOW, DOUBLE FEMALE
Valve for opening and closing fluid circuits.
Universal series, available from 1/8" to 1" parallel thread.

0471 - BALL VALVE WITH RIGHT ANGLED FLOW,MALE AND FEMALE0471 - BALL VALVE WITH RIGHT ANGLED FLOW,MALE AND FEMALE
Valve for opening and closing fluid circuits.
Universal series, available from 1/8" to 1" parallel thread.

0462 - BALL VALVE RIGHT ANGLED FLOW, DBLE FEM. WITH VENT0462 - BALL VALVE RIGHT ANGLED FLOW, DBLE FEM. WITH VENT
Standard vented ball valve.
Universal series, available from 1/8" to 1" parallel thread.

0461 - BALL VALVE RIGHT ANGLED FLOW,MALE & FEM. WITH VENT0461 - BALL VALVE RIGHT ANGLED FLOW,MALE & FEM. WITH VENT
Standard vented ball valve.
Universal series, available from 1/8" to 3/4" parallel thread.

0482 - 3 WAY BALL VALVE FEMALE RIGHT ANGLED PORTING0482 - 3 WAY BALL VALVE FEMALE RIGHT ANGLED PORTING
Female right angled three-way ball valve.
Universal series, available from 1/8" to 1" parallel thread.

0483 - 3 WAY BALL VALVE,FEM. RIGHT ANGLED PORTING0483 - 3 WAY BALL VALVE,FEM. RIGHT ANGLED PORTING
Three-way non-closing panel-mountable ball valve.
Universal series, available from 1/8" to 1" parallel thread.

0448 - 3 WAY BALL VALVE PANEL MOUNTABLE FEM. RIGHT ANGLED0448 - 3 WAY BALL VALVE PANEL MOUNTABLE FEM. RIGHT ANGLED
Panel mountable 3 way ball valve.
Universal series, available from 1/8" to 1/2" parallel thread.

0452 - 3 WAY BALL VALVE PANEL MOUNTABLE FEM. EQUAL PLANE0452 - 3 WAY BALL VALVE PANEL MOUNTABLE FEM. EQUAL PLANE
Panel mountable equal plane porting ball valve.
Universal series, available from 1/8" to 1/4" parallel thread.

0432 - IN-LINE DOUBLE FEMALE, BSPP0432 - IN-LINE DOUBLE FEMALE, BSPP
Lockable ball valve for opening and closing fluid circuits.
Universal series, available from 1/8" to 1" parallel thread.

0439 - DOUBLE FEMALE WITH VENT, BSPP0439 - DOUBLE FEMALE WITH VENT, BSPP
Vented lockable ball valve for opening and closing circuits.
Universal series, available from 1/8" to 1" parallel thread.

0436 - DOUBLE FEMALE WITH THREADED EXHAUST, BSPP0436 - DOUBLE FEMALE WITH THREADED EXHAUST, BSPP
Lockable ball valve for opening and closing fluid circuits.
Universal series, available from 3/8" to 1" parallel thread.

0437 - IN-LINE DOUBLE FEMALE VENTED, BSPP0437 - IN-LINE DOUBLE FEMALE VENTED, BSPP
Lockable ball valve for opening and closing fluid circuits. Lock in closed position to avoid potentially dangerous unintended operation.
Universal series, available from 1/4" to 1" parallel thread.

0438 - FEMALE 3 WAY, BSPP0438 - FEMALE 3 WAY, BSPP
Lockable ball valve for opening and closing fluid circuits. Lock in closed position to avoid potentially dangerous unintended operation.
Universal series, available from 3/8" to 1" parallel thread.

0499 - WITH THREADED EXHAUST, NPT0499 - WITH THREADED EXHAUST, NPTAllows for system vent while closing the valve and for the addition of a locking mechanism.
0492 - LIGHT SERIES BALL VALVES DOUBLE FEMALE0492 - LIGHT SERIES BALL VALVES DOUBLE FEMALE
Valve for opening and closing fluid circuits where dimensions are reduced.
Universal series, available from 1/4" to 3/4" parallel thread.

049C - 2/2 LIGHT SERIES BALL VALVES FEMALE SHORT HANDLE, FEMALE BSPP THREAD049C - 2/2 LIGHT SERIES BALL VALVES FEMALE SHORT HANDLE, FEMALE BSPP THREAD
Valve for opening and closing fluid circuits where dimensions are reduced.

0491 - LIGHT SERIES BALL VALVES MALE AND FEMALE0491 - LIGHT SERIES BALL VALVES MALE AND FEMALE
Valve for opening and closing fluid circuits where dimensions are reduced.
Universal series, available from 1/4" to 3/4" parallel thread.

049D - 2/2 LIGHT SERIES BALL VALVES SHORT HANDLE, MALE/FEMALE BSPP THREAD049D - 2/2 LIGHT SERIES BALL VALVES SHORT HANDLE, MALE/FEMALE BSPP THREAD
Valve for opening and closing fluid circuits where dimensions are reduced.

0490 - LIGHT SERIES BALL VALVES DOUBLE MALE0490 - LIGHT SERIES BALL VALVES DOUBLE MALE
Valve for opening and closing fluid circuits where dimensions are reduced.
Universal series, available from 1/4" to 3/4" parallel thread.

0494 - LIGHT SERIES VALVE DOUBLE FEMALE + 2 VENT PLUGS0494 - LIGHT SERIES VALVE DOUBLE FEMALE + 2 VENT PLUGS
Valve for opening and closing fluid circuits where dimensions are reduced.
Universal series, 3/8" parallel thread.

0497 - LENTICULAR SHUT-OFF VALVE DBLE FEMALE SQUARE STEM0497 - LENTICULAR SHUT-OFF VALVE DBLE FEMALE SQUARE STEMValve for opening and closing fluid circuits where dimensions are reduced.
0496 - LENTICULAR SHUT-OFF VALVE MALE&FEMALE SQUARE STEM0496 - LENTICULAR SHUT-OFF VALVE MALE&FEMALE SQUARE STEM
Valve for opening and closing fluid circuits where dimensions are reduced.
Universal series, available from 1/4" to 3/4" parallel thread.

4602 - LENTICULAR SHUT-OFF VALVE DOUBLE FEMALE4602 - LENTICULAR SHUT-OFF VALVE DOUBLE FEMALERecommended for carrying fluids including solid particles.
4902 - FEMALE/FEMALE, BSP PARALLEL4902 - FEMALE/FEMALE, BSP PARALLEL
Opening and closing a fluid system. Good pressure and temperature performance.
Standard series, available from 1/4" to 4" parallel thread.

4991 - 2/2 Standard Compact Series Ball Valve, Male/Female BSPP Thread4991 - 2/2 STANDARD COMPACT SERIES BALL VALVE, MALE/FEMALE BSPP THREAD
Enable opening and closing of a circuit in a machine where space is reduced.
Standard series, available from 1/8" to 1/2" parallel thread.

4992 - 2/2 Standard Compact Series Ball Valve, Double Female BSPP Thread4992 - 2/2 STANDARD COMPACT SERIES BALL VALVE, DOUBLE FEMALE BSPP THREAD
Enable opening and closing of a circuit in a machine where space is reduced.
Standard series, available from 1/8" to 1/2" parallel thread.

4962 - FEMALE 2 WAY BALL VALVE NPT4962 - FEMALE 2 WAY BALL VALVE NPTOpening and closing a fluid system. Good pressure and temperature performance.
