Parker Legris PFA tubing
Legris Fluoropolymer PFA Tubing
Parker Legris PFA tubing offers 10 times greater durability than other fluoropolymer tubings under severe chemical and mechanical conditions. This tubing range is available in three material grades, offering perfect compatibility with all applications.
Parker Legris PFA (perfluoroalkoxy) tubing offers 10 times greater durability than other fluoropolymer tubings (PTFE, FEP and PVDF) under severe chemical and mechanical conditions.
This tubing range is available in three material grades, offering perfect compatibility with all applications, even in extreme environments.
| Compatible Fitting: |
Industrial Fluids |
| Specifications Met: |
Medical: USP: Class VI (A), External communication devices//Industrial: UL94 V-0 (Fire resistance), DI: 2002/95/EC (RoHS), 2011/65/EC, DI: 97/23/EC (PED), RG:1907/2006 (REACH), DI: 94/09/EC (ATEX, black tubing)//Food Industry: FDA: 21 CFR 177.1550 (clear |
| Maximum Operating Temperature: |
302 °F, 150 °C |
| Minimum Operating Temperature: |
-40 °C, -40 °F |
| Tube Inside Diameter: |
2,5 to 10 mm |
| Tube Outside Diameter: |
4 to 12 mm |
| Tube Material: |
Fluorinated ethylene propylene (pure) (55 shore D) |
| Maximum Operating Pressure: |
36 bar |
| Vacuum Pressure Rating: |
755 mm-Hg |
| Weight: |
0,087 to 11,48 kg/package |
|
| Bend Radius: |
12 to 120 mm |
| Number of Tubes: |
1 |
| Application: |
Food-Process, Fuel Cells, Electrical/Electronics, Aircraft, Oil/Gas Industry, Pharmaceutical, Medical, Chemical, Clean Rooms |
| Media: |
Medical, bio-compatible, food process, gas, compressed air |
Features/Benefits:
- Great Versatility
- Exceptional chemical inertia
- A flexible alternative to stainless steel tubing
- Broad range of working temperatures, from cryogenic to extreme heat
- Non-stick properties allowing conveyance of many fluids & gases
- Outstanding resistance to ageing
- Fluoropolymer with the lowest permeability
- Non-flammable
- UV-transparent
- Tube marking on request
- Silicone-free
- Three Material Grades
- Clear High Purity PFA: to cover all applications, including those requiring maximum mechanical resistance
- Coloured PFA: for circuit identification
- Black Antistatic PFA: eliminates all risk of electrostatic discharge
Markets:
- Food and Beverage
- Power Generation Equipment
- Semiconductors
- Aircraft
- Pharmaceutical
- Medical
- Oil and Gas
Applications:
- Applications Subjected to Severe Mechanical and Chemical Conditions
- Medical Fluids Conveying
- Gas and Compressed Air Conveying
- Applications Requiring Very Low and High Temperature
- Fire Hazard Zones
- Applications Subjected to Intensive Cleaning
- Suitable for Fuel Cells and Clean Rooms
Technologies:
- Fluoropolymer Tubing
- PFA Tubing
- Perfluoroalkoxy Tubing
- Anti Static Tubing
- Industrial Tubing
Technical Characteristics:
Fluids: Medical, bio-compatible, food process, gas, compressed air
Materials: Perfluoroalkoxy
- High Purity PFA
- Translucent coloured PFA
- Antistatic PFA
Pressure: Vacuum to 36 bar
Temperature: -196°C to +260°C
Regulations:
Medical
- USP: Class VI (A)
External communication devices
Industrial
- UL94 V-0 (Fire resistance)
- DI: 2002/95/EC (RoHS), 2011/65/EC
- DI: 97/23/EC (PED)
- RG:1907/2006 (REACH)
- DI: 94/09/EC (ATEX, black tubing)
Food Industry
- FDA: 21 CFR 177.1550 (clear, translucent coloured)
- RG: 1935/2004
- NSF 51 (material)
Product Types:
- Fluoropolymer (PFA) Tubing
- Fluoropolymer (PFA) Antistatic Tubing
Related Documents
Literature and Reference Materials
Technical tubing and hose brochure
Chemical Compatibility Chart
Fluoropolymer Tubing PFA Datasheet
Packaging For Technical Tubing And Hose
Parker Legris--Connection Solutions up to 150°C for Coffee Machine
Principle and Advantages of Our Coupling Systems
Technical Tubing And Hose
Tubing Part Number Identification
Contact & Support Information
Contact & Support
Selector Guides
Chemical Compatibility Chart
Compliance, Certifications, & Safety
Certificate of conformity - 2014 68 EU_connectic
Certificate of conformity - Mineral Conflict Statement_connectic
Certificate of conformity - REACH_Statement
Certificate of conformity - RoHS 3_connectic
- Fluoropolymer PFA Tubing Ordering Number
訂貨型號(hào)
Part |
Tubing Material |
Tube O.D. (mm) |
Tube I.D. (mm) |
Color |
Length (m) |
1010T04A01 |
ANTISTATIC PFA TUBING |
4 |
2 |
BLACK |
10 |
1010T06A01 |
ANTISTATIC PFA TUBING |
6 |
4 |
BLACK |
10 |
1010T08A01 |
ANTISTATIC PFA TUBING |
8 |
6 |
BLACK |
10 |
1050T04P00 |
PFA HIGH PURITY OR COLOURED |
4 |
2 |
NATURAL |
50 |
1050T04P12 |
PFA HIGH PURITY OR COLOURED |
4 |
2 |
GREEN CRYSTAL |
50 |
1050T04P13 |
PFA HIGH PURITY OR COLOURED |
4 |
2 |
RED CRYSTAL |
50 |
1050T04P14 |
PFA HIGH PURITY OR COLOURED |
4 |
2 |
BLUE CRYSTAL |
50 |
1050T06P00 |
PFA HIGH PURITY OR COLOURED |
6 |
4 |
NATURAL |
50 |
1050T06P12 |
PFA HIGH PURITY OR COLOURED |
6 |
4 |
GREEN CRYSTAL |
50 |
1050T06P13 |
PFA HIGH PURITY OR COLOURED |
6 |
4 |
RED CRYSTAL |
50 |
1050T06P14 |
PFA HIGH PURITY OR COLOURED |
6 |
4 |
BLUE CRYSTAL |
50 |
1050T08P00 |
PFA HIGH PURITY OR COLOURED |
8 |
6 |
NATURAL |
50 |
1050T08P12 |
PFA HIGH PURITY OR COLOURED |
8 |
6 |
GREEN CRYSTAL |
50 |
1050T08P13 |
PFA HIGH PURITY OR COLOURED |
8 |
6 |
RED CRYSTAL |
50 |
1050T08P14 |
PFA HIGH PURITY OR COLOURED |
8 |
6 |
BLUE CRYSTAL |
50 |
1050T10P00 |
PFA HIGH PURITY OR COLOURED |
10 |
8 |
NATURAL |
50 |
1050T12P00 |
PFA HIGH PURITY OR COLOURED |
12 |
9 |
NATURAL |
50 |
1100T04P00 |
PFA HIGH PURITY OR COLOURED |
4 |
2 |
NATURAL |
100 |
1100T06P00 |
PFA HIGH PURITY OR COLOURED |
6 |
4 |
NATURAL |
100 |
1100T08P00 |
PFA HIGH PURITY OR COLOURED |
8 |
6 |
NATURAL |
100 |
1100T10P00 |
PFA HIGH PURITY OR COLOURED |
10 |
8 |
NATURAL |
100 |
1100T12P00 |
PFA HIGH PURITY OR COLOURED |
12 |
9 |
NATURAL |
100 |
|
