Parker 快速接頭和附件
Parker Quick Couplings and Accessories
Parker Quick Couplings
Hydraulic Quick Coupling with ISO B Profile, Series IB
Parker's Hydraulic Quick Coupling Series IB plug profiles
Parker派克的液壓快速接頭系列IB插頭 符合IS0標準7241-1系列B，并且與其他符合同一標準的系列兼容。為了優化性能和抗腐蝕性能，快速接頭由黃銅制成，插頭由硬鋼制成。IB系列具有消除壓力功能，可以輕松連接靜壓和殘余壓力，直至工作壓力。壓力消除器可用于插頭和接頭。帶有重型套筒的選件在非常艱苦的應用中具有更長的使用壽命。快速連接系統，閥體尺寸為1/4“到1”，最大壓力為400 bar。ISO 7241-1系列B型材的快速連接系統。
Parker's Hydraulic Quick Coupling Series IB plug profiles
Hydraulic Quick Coupling with ISO B Profile, Series IB
Parker's Hydraulic Quick Coupling Series IB plug profiles are conform to IS0 Standard 7241-1 series B and are compatible with other series complying with the same standard. To optimize performance and corrosion resisitance the coupling is made of brass and the plug made of hardend steel. Series IB is available with pressure eliminator function, which allows for effortless connection with static and residual pressure, up to operating pressure. A pressure eliminator is available for plugs and couplings. The option with heavy duty sleeve gives a longer life time in very tough applications. Quick coupling system with body size 1/4" up to 1" for medium pressure applications up to 400 bar. Coupling system with ISO 7241-1 Series B profile.
市場：
-農業
-汽車
-石油和天然氣
-加工
-發電
-運輸
-職業與市政
-國防
-工業
-機床
-材料處理
-結構
特征/優點：
-可用壓力消除器在殘余壓力下連接
-配有重型套筒，在非常惡劣的應用中具有更長的使用壽命
-銅制快速接頭可避免腐蝕
應用：
易于連接在移動和工業液壓系統中的斷開/斷開
-拖拉機
-卡車
-輪式裝載機
-軍車
-壓力機
Markets:
- Agriculture
- Automotive
- Oil & Gas
- Process
- Power Generation
- Transportation
- Vocational & Municipal
- Defense
- Industrial
- Machine Tooling
- Material Handling
- Construction
Features/Benefits:
- Available with pressure eliminator to connect under residual pressure
- Available with heavy duty sleeve for longer life time in very tough applications
- Coupling made of brass to avoid corrosion
Applications:
Easy connection / disconnectionin hydraulic systems, both mobile and industrial applications
- Tractors
- Trucks
- Wheel loaders
- Military vehicles
- Presses
Technical Specifications
| Minimum Operating Temperature: |
-25, -30 °C |
| Application: |
Medium Pressure |
| Brand: |
Tema |
| Fitting Connection Type: |
Female Thread |
| Specifications Met: |
ISO 7241-1 Series B |
| Interchange Type: |
ISO 7241-1 Series B |
| Maximum Operating Pressure: |
250, 300, 320, 400 bar, 3620, 4350, 4640, 5800 psi |
| Maximum Operating Temperature: |
212, 392 °F, 100, 200 °C |
| Media: |
Hydraulic Fluids, Steam, Water |
| Seal Material: |
NBR / FKM |
| Valve Type: |
Poppet |
| Body Size: |
1/4 - 1 inch |
| Connection Type: |
Female Thread |
| Length: |
38 up to 94 mm |
| Hex Size: |
19 up to 50 mm |
| Outside Diameter: |
28 up to 66 mm |
| Materials of Construction: |
Brass, Steel |
| Operating Pressure: |
250, 300, 320, 400 bar |
Hydraulic Quick Coupling with ISO B Profile, Series IB 型號
| Part |
Type |
Valving |
Version |
Connection Thread Size (inch) |
Seal Material |
| IB10010 |
Coupling |
with |
Standard |
1 |
NBR |
| IB10010 H |
Coupling with Heavy Duty Sleeve |
with |
Standard |
1 |
NBR |
| IB10010 HUV |
Coupling with Heavy Duty Sleeve |
without |
Standard |
1 |
NBR |
| IB10010 HV |
Coupling with Heavy Duty Sleeve |
with |
Standard |
1 |
FKM |
| IB10010 HVUV |
Coupling with Heavy Duty Sleeve |
without |
Standard |
1 |
FKM |
| IB10010 UV |
Coupling |
without |
Standard |
1 |
NBR |
| IB10010 V |
Coupling |
with |
Standard |
1 |
FKM |
| IB10010 VUV |
Coupling |
without |
Standard |
1 |
FKM |
| IB10011 |
Coupling |
with |
with Pressure Eliminator |
1 |
NBR |
| IB10011 H |
Coupling with Heavy Duty Sleeve |
with |
with Pressure Eliminator |
1 |
NBR |
| IB10020 |
Plug |
with |
Standard |
1 |
NBR |
| IB10020 UV |
Plug |
without |
Standard |
1 |
na |
| IB10020 V |
Plug |
with |
Standard |
1 |
FKM |
| IB10021 |
Plug |
with |
with Pressure Eliminator |
1 |
NBR |
| IB2510 |
Coupling |
with |
Standard |
1/4 |
NBR |
| IB2510 UV |
Coupling |
without |
Standard |
1/4 |
NBR |
| IB2510 V |
Coupling |
with |
Standard |
1/4 |
FKM |
| IB2510 VUV |
Coupling |
without |
Standard |
1/4 |
FKM |
| IB2511 |
Coupling |
with |
with Pressure Eliminator |
1/4 |
NBR |
| IB2511 V |
Coupling |
with |
with Pressure Eliminator |
1/4 |
FKM |
| IB2520 |
Plug |
with |
Standard |
1/4 |
NBR |
| IB2520 UV |
Plug |
without |
Standard |
1/4 |
na |
| IB2520 V |
Plug |
with |
Standard |
1/4 |
FKM |
| IB2521 |
Plug |
with |
with Pressure Eliminator |
1/4 |
NBR |
| IB2521 V |
Plug |
with |
with Pressure Eliminator |
1/4 |
FKM |
| IB3810 |
Coupling |
with |
Standard |
3/8 |
NBR |
| IB3810 UV |
Coupling |
without |
Standard |
3/8 |
NBR |
| IB3810 V |
Coupling |
with |
Standard |
3/8 |
FKM |
| IB3810 VUV |
Coupling |
without |
Standard |
3/8 |
FKM |
| IB3811 |
Coupling |
with |
with Pressure Eliminator |
3/8 |
NBR |
| IB3811 V |
Coupling |
with |
with Pressure Eliminator |
3/8 |
FKM |
| IB3820 |
Plug |
with |
Standard |
3/8 |
NBR |
| IB3820 UV |
Plug |
without |
Standard |
3/8 |
na |
| IB3820 V |
Plug |
with |
Standard |
3/8 |
FKM |
| IB3821 |
Plug |
with |
with Pressure Eliminator |
3/8 |
NBR |
| IB3821 V |
Plug |
with |
with Pressure Eliminator |
3/8 |
FKM |
| IB5010 |
Coupling |
with |
Standard |
1/2 |
NBR |
| IB5010 H |
Coupling with Heavy Duty Sleeve |
with |
Standard |
1/2 |
NBR |
| IB5010 HUV |
Coupling with Heavy Duty Sleeve |
without |
Standard |
1/2 |
NBR |
| IB5010 UV |
Coupling |
without |
Standard |
1/2 |
NBR |
| IB5010 V |
Coupling |
with |
Standard |
1/2 |
FKM |
| IB5010 VUV |
Coupling |
without |
Standard |
1/2 |
FKM |
| IB5011 |
Coupling |
with |
with Pressure Eliminator |
1/2 |
NBR |
| IB5011 H |
Coupling with Heavy Duty Sleeve |
with |
with Pressure Eliminator |
1/2 |
NBR |
| IB5011 V |
Coupling |
with |
with Pressure Eliminator |
1/2 |
FKM |
| IB5020 |
Plug |
with |
Standard |
1/2 |
NBR |
| IB5020 UV |
Plug |
without |
Standard |
1/2 |
na |
| IB5020 V |
Plug |
with |
Standard |
1/2 |
FKM |
| IB5021 |
Plug |
with |
with Pressure Eliminator |
1/2 |
NBR |
| IB5021 V |
Plug |
with |
with Pressure Eliminator |
1/2 |
FKM |
| IB7510 |
Coupling |
with |
Standard |
3/4 |
NBR |
| IB7510 H |
Coupling with Heavy Duty Sleeve |
with |
Standard |
3/4 |
NBR |
| IB7510 HUV |
Coupling with Heavy Duty Sleeve |
without |
Standard |
3/4 |
NBR |
| IB7510 UV |
Coupling |
without |
Standard |
3/4 |
NBR |
| IB7510 V |
Coupling |
with |
Standard |
3/4 |
FKM |
| IB7510 VUV |
Coupling |
without |
Standard |
3/4 |
FKM |
| IB7511 |
Coupling |
with |
with Pressure Eliminator |
3/4 |
NBR |
| IB7511 H |
Coupling with Heavy Duty Sleeve |
with |
with Pressure Eliminator |
3/4 |
NBR |
| IB7511 V |
Coupling |
with |
with Pressure Eliminator |
3/4 |
FKM |
| IB7520 |
Plug |
with |
Standard |
3/4 |
NBR |
| IB7520 UV |
Plug |
without |
Standard |
3/4 |
na |
| IB7520 V |
Plug |
with |
Standard |
3/4 |
FKM |
| IB7521 |
Plug |
with |
with Pressure Eliminator |
3/4 |
NBR |
| IB7521 V |
Plug |
with |
with Pressure Eliminator |
3/4 |
FKM |
|
