Parker Orifice Fittings
Parker Fittings接頭 - Hydraulic Fittings

派克緊湊且具有成本效益的節流孔配件允許 OEM 在工廠預設特定液壓管或軟管管線中的特定節流孔，從而消除或最大限度地減少對昂貴的流量控制閥的需求。派克的孔口接頭有 37° 擴口和 O 形環面密封 (ORFS) 兩種配置。這些緊湊且具有成本效益的孔口配件允許原始設備制造商在工廠預設特定液壓管或軟管管線中的指定孔口，從而消除或最大限度地減少對昂貴流量控制閥的需求。Parker's compact and cost effective Orifice Fittings allow OEMs to pre-set, at the factory, a specified orifice in specific hydraulic tube or hose lines, which eliminates or minimizes the need for costly flow control valves. Parker's Orifice Fittings come in both 37° flare and O-ring face seal (ORFS) configurations. These compact and cost effective orifice fittings allow OEMs to pre-set, at the factory, a specified orifice in specific hydraulic tube or hose lines, which eliminates or minimizes the need for costly flow control valves.

Orifice Fittings

市場：
- 建筑
- 農業
- 采礦
- 石油和天然氣
- 運輸
- 替代燃料

特性/優點：
- 提供常用的預設孔口尺寸，孔口配件使 OEM 能夠控制最終工廠建立的液壓系統流量和速度特性。
- 專為永久或臨時安裝而設計，只需在軟管旋轉接頭和適配器之間進行簡單連接，即可將孔口接頭輕松安裝到液壓系統中。
- 孔口尺寸永久印在閥體上以便于識別。
- 可以消除或盡量減少昂貴的流量控制閥。
- 也可根據要求提供一系列可替代傳統端口適配器的孔口適配器。
- 提供尺寸為 1/4”、3/8” 和 ?” 的鋼材質，工作壓力高達 12,000 psi。

應用：
- 液壓馬達的固定轉速。
- 氣缸伸出或縮回的固定速度。

Markets:
- Construction
- Agriculture
- Mining
- Oil & Gas
- Transportation
- Alternative fuel

Features/Benefits:
- Available in commonly pre-set orifice sizes, orifice fittings provide OEMs with control over final factory established flow and speed characteristics of the hydraulic system.
- Designed for permanent or temporary installation, orifice fittings can be easily installed in-line into hydraulic system by simply connecting between hose swivel and adapter.
- Orifice size is permanently stamped on body for ease of identification.
- Can eliminate or minimize costly flow control valves.
- A line of orifice adapters that will replace a traditional port adapter is also available upon request.
- Available in steel in sizes 1/4”, 3/8” and ?” with working pressures up to 12,000 psi.

Applications:
- Fixed rotation speed for hydraulic motors.
- Fixed speed on cylinder extend or retract.

Technical Specifications

Orifice Fittings 型號
