Ermeto 高壓液壓焊接隔板 Parker Fittings接頭 Flareless and Bite Type Fittings
Ermeto high pressure hydraulic weld bulkhead

Ermeto 焊接隔板適用于所有流行的焊接配件，并滿足復雜焊接程序中對單個組件的嚴格要求。Ermeto 焊接隔板，ESV 型，能夠通過隔板隔板連接具有相同外徑的直線公制管道，并通過焊接固定到隔板隔板上。Ermeto 焊接隔板可提供從 6 – 38/42 的輕型和重型系列的所有尺寸。Ermeto weld bulkheads are suitable for all popular weld fittings and meet the stringent requirements which are placed on individual components in complex welding procedures. Ermeto weld bulkheads, type ESV, enable the connection of straight metric tube lines with identical outer diameters through a bulkhead partition and secured by welding to the bulkhead partition. Ermeto weld bulkheads are available in all sizes from 6 – 38/42 in the light and heavy series.

Ermeto high pressure hydraulic weld bulkhead

市場：
- 壓力機制造
- 重型機械制造
- 電站建設
- 造船

應用：
- 適用于一般液壓應用。

特點與優勢：
- Ermeto 焊接隔板，ESV 型，能夠通過隔板隔板連接具有相同外徑的直線公制管道，并通過焊接固定到隔板隔板。
- 焊接隔板采用不銹鋼制成。鋼制版本具有強耐腐蝕的無 Cr(VI) 版本，可延長組件的生命周期。
- 組裝不當的焊接隔板不會在沒有警告的情況下分開。用戶可以盡早做出反應，因為連接器會通過泄漏來指示問題，并且可以重新擰緊。

Markets:
- Press construction
- Heavy machinery building
- Power station construction
- Shipbuilding

Applications:
- Suitable for general hydraulic applications.

Features/ benefits:
- Ermeto weld bulkheads, type ESV, enable the connection of straight metric tube lines with identical outer diameters through a bulkhead partition and secured by welding to the bulkhead partition.
- Weld bulkheads are available in stainless steel. The steel version is with a strong corrosion resistant Cr(VI)-free version, which extends the lifetime cycle of the component.
- Insufficiently assembled weld bulkheads do not come apart without warning. The user can react early enough because the connectors indicate the problem by leaking and they can be retightened.

Technical Specifications

Ermeto high pressure hydraulic weld bulkhead型號
