Parker 派克 EO高壓彎管焊接接頭 | #SKA20X4RB

Parker Fittings接頭 Flareless and Bite Type Fittings
Ermeto high pressure hydraulic tube bend weld nipple

Parker 派克 EO高壓彎管焊接接頭是一種廣受歡迎的焊接接頭類型，且符合復雜的焊接流程對于單個零件的嚴格標準要求。EO彎管焊接接頭SKA-RB系列可與EO接頭裝配連接。無論輕重系列，該接頭的尺寸范圍均從6mm至38mm。EO彎管焊接接頭的焊接端可與硬管焊接而無需使用O形圈，在焊接之前，需將正確尺寸的螺母按照正確的方向預裝配好。在焊接過程中，管端預處理、實際焊接操作、焊接人員的資質認證、后續處理、產品測試及存檔等流程可能需要符合相關的標準和法規。EO高壓彎管焊接接頭特征/優勢：- EO彎管焊接接頭可與任意EO接頭裝配連接，因此擁有廣泛的應用范圍。- 彈性密封圈作為主要的密封元件，以獲得連接系統密封的穩定性，因此維護和返修的成本大大降低。- 即使連續多年在嚴苛工況下長期工作，該彈性密封EO彎管焊接接頭也無需重新擰緊。這也就意味著該連接方式擁有更長的使用壽命，且維護和維修成本均顯著降低。- EO彎管焊接接頭可無限次重復拆裝。此特性也使得該連接方式擁有更長的使用壽命并降低了成本。EO高壓彎管焊接接頭應用- 適用于通用液壓系統。

Ermeto high pressure hydraulic tube bend weld nipple

Ermeto tube bend weld nipples are suitable for all popular weld fittings and meet the stringent requirements which are placed on individual components in complex welding procedures. Ermeto SKA-RB tube bend weld nipple types can be assembled in any Ermeto tube fitting. Ermeto tube bend weld nipples are available in all sizes from 6 – 38 in the light and heavy series. The Ermeto tube bend weld nipple is welded to the tube end without the O-ring. Assembling beforehand a retaining nut with the right size and orientation should not be forgotten. Special guidelines and regulations may apply to the pre-handling of the tube end, the welding procedure, welding personnel qualifications, post-processing and testing and documentation of the weld connection.

市場：
- 沖壓設備廠
- 重型機械廠
- 發電廠
- 造船廠

應用：
- 適用于通用液壓系統。

特征/優勢：
- EO彎管焊接接頭可與任意EO接頭裝配連接，因此擁有廣泛的應用范圍。
- 彈性密封圈作為主要的密封元件，以獲得連接系統密封的穩定性，因此維護和返修的成本大大降低。
- 即使連續多年在嚴苛工況下長期工作，該彈性密封EO彎管焊接接頭也無需重新擰緊。這也就意味著該連接方式擁有更長的使用壽命，且維護和維修成本均顯著降低。
- EO彎管焊接接頭可無限次重復拆裝。此特性也使得該連接方式擁有更長的使用壽命并降低了成本。

Markets:
- Press construction
- Heavy machinery building
- Power station construction
- Shipbuilding

Applications:
- Suitable for general hydraulic applications.

Features/ benefits:
- Ermeto tube bend weld nipples can be combined with all EO fittings,so that the fittings can be used in a wide range of applications.
- The elastomeric seal acts as a primary sealing element, making the connection leak-proof. So maintenance and re-work costs are substantially reduced.
- Insufficiently assembled tube bend weld nipple connectors do not come apart without warning. The user can react early enough because the connectors indicate the problem by leaking and they can be retightened.
- Ermeto tube bend weld nipple connectors can be undone and then re-assembled any number of times. The longevity of the connector is thereby increased and costs saved.

Technical Specifications

Ermeto high pressure hydraulic tube bend weld nipple型號
