Parker 球閥 - Parker Ball Valves
Ball Valve Series BVGL & BVGLOCK - Long Female Threads

Ball Valve Series BVGL & BVGLOCK - Long Female Threads | #BVG4-1L

BVGL＆BVGLOCK系列球閥具有鍍鎳黃銅閥體和鍍鉻黃銅閥球，并且為長內螺紋結構設計。派克的BVGL＆BVGL系列球閥按照DIN 2999 / ISO 228標準制造，帶有長內螺紋。這使得該閥既可以與Prestolok和黃銅轉換接頭一起使用，也可以與派克的碳鋼液壓接頭（例如Tiple-Lok，O-Lok，EO和BSPP錐螺紋接頭）一起使用。

這些球閥配有防擠壓桿，以防止在壓力峰值時爆裂。閥桿由兩個氟碳O形圈密封，以實現更大的安全性和性能。所有閥門均為全流量。這限制了流體通過閥門時所產生的湍流，從而將壓降降至較低。

BVGLOCK球閥具有可鎖定的手柄和PTFE填料壓蓋。BVGLOCK球閥符合歐洲指令DI 89/392 / CEE中有關電源隔離的要求，并符合DU Travail法規L233-5段中有關機器和材料的健康和安全要求。

Ball Valve Series BVGL & BVGLOCK - Long Female Threads

市場：
- 工業
- 交通運輸
- 石油和加油站
- 化學

特點與優勢：
- 鍍鎳黃銅主體
- 鍍鉻黃銅球
- PTFE閥座/密封
- 氟碳管密封

應用范圍：
- 汽車
- 清潔工具

BVGL & BVGLOCK series ball valves feature a nickel plated brass body and a chrome plated brass ball and are manufactured with long female threads.

Parker's BVGL & BVGL series ball valves are manufactured with long female threads in accordance to DIN 2999/ISO 228. This enables the valves to be used with Prestolok and brass adaptors but also Parker's range of steel hydraulic fittings, e.g. Tiple-Lok, O-Lok, EO, and BSPP coned adaptors.

These ball valves are fitted with an anti extrusion stem to prevent blow out in the case of pressure peaks. The stem is sealed with two Fluorocarbon O-rings for maximum safety and performance. All valves are full-flow. This limits the turbulence created by the passage of fluid across the valve, minimizing pressure drop.

The BVGLOCK ball valves feature a lockable handle and a PTFE packing gland. The BVGLOCK ball valves meet the requirements of European directive DI 89/392/CEE relating to the isolation of power supply and to meet the health and safety requirements for machines and materials in paragraphs L233-5 of the code DU Travail.

Markets:
- Industrial
- Transportation
- Oil & Gas
- Chemical

Features/Benefits:
- Nickel plated brass body
- Chrome plated brass ball
- PTFE seats/seals
- Fluorocarbon stem seal

Applications:
- Automotive
- Cleaning Equipment

Technical Specifications

Ball Valve Series BVGL & BVGLOCK - Long Female Threads 型號
