Parker Legris樂可利精密優質PU聚醚管 1025U - FLEXIBLE POLYURETHANE TUBING, 25 M ROLLS
Legris樂可利精密優質PU聚醚管
Parker Legris樂可利 1025U - 精密軟質PU管, 25米裝。
適用于需要有緊湊的外形和良好的彈性，安裝在狹小的空間；出色的抗磨損性能，多種顏色可區分不同的回路 。Legris樂可利聚醚PU管，這款樂可利聚醚PU管一般適用于液體的環境使用，具體非常強的抗濕能力，和抗細菌腐蝕能力，透明的管路可以看清里面的液體。
詳細介紹
Legris樂可利精密優質PU聚醚管是一款非常好的精密軟質PU管，小小的管子，具有太多太多的優點，每卷Legrsi樂可利PU聚醚管長度為25米
- 具有極好的柔軟性，彎曲半徑小；
-工作溫度及工作壓力范圍寬；
- 有極好的化學性能，壓力損失極��；
- 硬度恒定，使用壽命長；
- 具有抗震性，防U.V.性能；
- 極佳的抗濕性能，抗細菌侵蝕性能；
- 透明管可直接看清管內流體3種顏色可供選擇，易于管路識別
產品編號 |
顏色 |
o.d. (MM) |
i.d. (MM) |
Pack Qty |
| 1025U03 01 18 |
 |
3 |
1,8 |
1 |
| 1025U03 04 18 |
 |
3 |
1,8 |
1 |
| 1025U04 01 |
|
4 |
2,5 |
1 |
| 1025U04 02 |
 |
4 |
2,5 |
1 |
| 1025U04 03 |
 |
4 |
2,5 |
1 |
| 1025U04 04 |
|
4 |
2,5 |
1 |
| 1025U04 05 |
 |
4 |
2,5 |
1 |
| 1025U04 06 |
 |
4 |
2,5 |
1 |
| 1025U05 01 |
|
5 |
3 |
1 |
| 1025U05 04 |
|
5 |
3 |
1 |
| 1025U06 01 |
|
6 |
4 |
1 |
| 1025U06 02 |
|
6 |
4 |
1 |
| 1025U06 03 |
|
6 |
4 |
1 |
| 1025U06 04 |
|
6 |
4 |
1 |
| 1025U06 05 |
|
6 |
4 |
1 |
| 1025U06 06 |
|
6 |
4 |
1 |
| 1025U08 01 |
|
8 |
5,5 |
1 |
| 1025U08 02 |
|
8 |
5,5 |
1 |
| 1025U08 03 |
|
8 |
5,5 |
1 |
| 1025U08 04 |
|
8 |
5,5 |
1 |
| 1025U08 05 |
|
8 |
5,5 |
1 |
| 1025U08 06 |
|
8 |
5,5 |
1 |
| 1025U10 01 |
|
10 |
7 |
1 |
| 1025U10 02 |
|
10 |
7 |
1 |
| 1025U10 04 |
|
10 |
7 |
1 |
| 1025U10 05 |
|
10 |
7 |
1 |
| 1025U10 06 |
|
10 |
7 |
1 |
| 1025U12 01 |
|
12 |
8 |
1 |
| 1025U12 02 |
|
12 |
8 |
1 |
| 1025U12 04 |
|
12 |
8 |
1 |
| 1025U12 05 |
|
12 |
8 |
1 |
| 1025U12 06 |
|
12 |
8 |
1 |
| 1025U14 01 95 |
|
14 |
9,5 |
1 |
| 1025U14 04 95 |
|
14 |
9,5 |
1 |
| 1025U16 01 11 |
|
16 |
11 |
1 |
| 1025U16 02 11 |
|
16 |
11 |
1 |
| 1025U16 03 11 |
|
16 |
11 |
1 |
| 1025U16 04 11 |
|
16 |
11 |
1 |
Parker Legris派克樂可利工業流體連接件產品領域
1025U - 精密軟質PU管, 25米裝適用于需要有緊湊的外形和良好的彈性，安裝在狹小的空間
1100U - 精密軟質PU管, 100米裝1100U - 精密軟質PU管, 100米裝適用于需要有緊湊的外形和良好的彈性，安裝在狹小的空間
1025U..R - 精密軟質PU聚醚管, 25米裝1025U..R - 精密軟質PU聚醚管, 25米裝適用于需要有緊湊的外形和良好的彈性，具有良好的耐濕性可安裝在狹小的空間
1100U ..R - 精密軟質PU聚醚管, 100米裝1100U ..R - 精密軟質PU聚醚管, 100米裝適用于需要有緊湊的外形和良好的彈性，具有良好的耐濕性可安裝在狹小的空間
2003U - 聚醚PU管，300米包裝2003U - 聚醚PU管，300米包裝
具有極好的柔軟性，非常適用于狹小空間氣路的安裝，同時具有良好的耐濕性和抗老化性能
2005U - 聚酯類PU管, 500米一卷2005U - 聚酯類PU管, 500米一卷適用于需要線路緊湊,氣管的彎曲半徑很小的場合.
具有優異的抗化學性能和抗老化性能
2010U - 聚酯類PU管, 1000米一卷2010U - 聚酯類PU管, 1000米一卷適用于需要線路緊湊,氣管的彎曲半徑很小的場合.
具有優異的抗化學性能和抗老化性能
2003U..R - 聚醚PU管，300米包裝2003U..R - 聚醚PU管，300米包裝
具有極好的柔軟性，非常適用于狹小空間的氣路的安裝，同時具有良好的耐濕和抗細菌性能
2005U..R - 聚醚類PU管, 500米一卷2005U..R - 聚醚類PU管, 500米一卷適用于需要線路緊湊,氣管的彎曲半徑很小的場合.
具有優異的抗化學性能和抗老化性能
2010U..R - 聚醚PU管，1000米包裝2010U..R - 聚醚PU管，1000米包裝
具有極好的柔軟性，非常適用于狹小空間的氣路的安裝，同時具有良好的耐濕和抗細菌性能
1025U..G - CLEANFIT SEMI-RIGID PU ETHER TUBING CLEAN, ISO 7, 25 M1025U..G - CLEANFIT SEMI-RIGID PU ETHER TUBING CLEAN, ISO 7, 25 M
This range of CleanFit tubing ensures a high level of cleanliness for clean rooms or medical applications.
Parker Legris tubing is easy to use on portable devices and reduced spaces and contributes to increase patient comfort.
Our tubes are also ISO 15001-compatible and guarantee a superior level of cleanliness, thereby optimising fluid performance and increasing safety and reliability.
1100U..A - ANTI-STATIC POLYURETHANE POLYESTER TUBING 100 M1100U..A - ANTI-STATIC POLYURETHANE POLYESTER TUBING 100 M低表面電阻設計，具有防靜電的功能
1025U..V - 雙層防火花PU管 25 米裝1025U..V - 雙層防火花PU管 25 米裝用于焊接場合
1100U..V - 雙層防火花PU管 100 米裝1100U..V - 雙層防火花PU管 100 米裝用于焊接場合
1025U..K - 單層防火花PU管 25米裝1025U..K - 單層防火花PU管 25米裝用于焊接場合
1100U..K - 單層防火花PU管 100米裝1100U..K - 單層防火花PU管 100米裝用于焊接場合
1420U - PU雙排管, 25米裝1420U - PU雙排管, 25米裝外形緊湊，安裝方便
1470U - PU螺旋管 2 米, 帶BSPT錐螺紋接頭(即PT斜螺紋)1470U - PU螺旋管 2 米, 帶BSPT錐螺紋接頭(即PT斜螺紋)適用于手動安裝
1471U - PU螺旋管 4 米, 帶BSPT錐螺紋接頭(即PT斜螺紋)1471U - PU螺旋管 4 米, 帶BSPT錐螺紋接頭(即PT斜螺紋)適用于手動安裝
1472U - PU螺旋管 6 米, 帶BSPT錐螺紋接頭(即PT斜螺紋)1472U - PU螺旋管 6 米, 帶BSPT錐螺紋接頭(即PT斜螺紋)適用于手動安裝
1460U - PU螺旋管 2 米, 不帶接頭1460U - PU螺旋管 2 米, 不帶接頭適用于手動安裝
1461U - PU螺旋管 4 米, 不帶接頭1461U - PU螺旋管 4 米, 不帶接頭適用于手動安裝
1462U - PU螺旋管 6 米, 不帶接頭1462U - PU螺旋管 6 米, 不帶接頭適用于手動安裝
1094U - 精密軟質PU管, 100英呎裝1094U - 精密軟質PU管, 100英呎裝適用于需要有緊湊的外形和良好的彈性，安裝在狹小的空間
樂可利產品型號
MULTITUBE
1025U - FLEXIBLE POLYURETHANE TUBING, 25 M ROLLS1025U - FLEXIBLE POLYURETHANE TUBING, 25 M ROLLSUsed for compact installations requiring a small bend radius and high flexibility.
1100U - FLEXIBLE POLYURETHANE TUBING, 100 M ROLLS1100U - FLEXIBLE POLYURETHANE TUBING, 100 M ROLLSUsed for compact installations requiring a small bend radius and high flexibility.
1025U..R - FLEXIBLE POLYURETHANE POLYETHER TUBING, 25 M1025U..R - FLEXIBLE POLYURETHANE POLYETHER TUBING, 25 MResistant to humidity and for use in compact installations requiring small bend radius and high flexibility.
1100U ..R - FLEXIBLE POLYETHER POLYURETHANE TUBING, 100 M1100U ..R - FLEXIBLE POLYETHER POLYURETHANE TUBING, 100 MResistant to humidity and for use in compact installations requiring small bend radius and high flexibility.
2003U - POLYESTER POLYURETHANE TUBING, 300 M ROLLS2003U - POLYESTER POLYURETHANE TUBING, 300 M ROLLS
Used for compact installations requiring a small bend radius and high flexibility. Excellent chemical resistance and ageing.
2005U - POLYESTER POLYURETHANE TUBING, 500 M ROLLS2005U - POLYESTER POLYURETHANE TUBING, 500 M ROLLSUsed for compact installations requiring a small bend radius and high flexibility.
Excellent chemical resistance and ageing.
2010U - POLYESTER POLYURETHANE TUBING, 1000 M ROLLS2010U - POLYESTER POLYURETHANE TUBING, 1000 M ROLLSUsed for compact installations requiring a small bend radius and high flexibility.
Excellent chemical resistance and ageing.
2003U..R - POLYETHER POLYURETHANE TUBING, 300 M ROLLS2003U..R - POLYETHER POLYURETHANE TUBING, 300 M ROLLS
Used for compact installations requiring a small bend radius and high flexibility. Excellent resistance to humidity and bactoriogical aggressions.
2005U..R - POLYETHER POLYURETHANE TUBING, 500 M ROLLS2005U..R - POLYETHER POLYURETHANE TUBING, 500 M ROLLSUsed for compact installations requiring a small bend radius and high flexibility.
Excellent resistance to humidity and bacteriological agressions.
2010U..R - POLYETHER POLYURETHANE TUBING, 1000 M ROLLS2010U..R - POLYETHER POLYURETHANE TUBING, 1000 M ROLLS
Used for compact installations requiring a small bend radius and high flexibility. Excellent resistance to humidity and bactoriogical aggressions.
1025U..G - CLEANFIT SEMI-RIGID PU ETHER TUBING CLEAN, ISO 7, 25 M1025U..G - CLEANFIT SEMI-RIGID PU ETHER TUBING CLEAN, ISO 7, 25 M
This range of CleanFit tubing ensures a high level of cleanliness for clean rooms or medical applications.
Parker Legris tubing is easy to use on portable devices and reduced spaces and contributes to increase patient comfort.
Our tubes are also ISO 15001-compatible and guarantee a superior level of cleanliness, thereby optimising fluid performance and increasing safety and reliability.
1100U..A - ANTI-STATIC POLYURETHANE POLYESTER TUBING 100 M1100U..A - ANTI-STATIC POLYURETHANE POLYESTER TUBING 100 MAnti-spark and low surface resistance.
1025U..V - WITH A SHEATH ANTI-SPARK 25M ROLLS1025U..V - WITH A SHEATH ANTI-SPARK 25M ROLLSUsed for welding applications.
1100U..V - WITH A SHEATH ANTI-SPARK 100 M ROLLS1100U..V - WITH A SHEATH ANTI-SPARK 100 M ROLLSUsed for welding applications.
1025U..K - POLYURETHANE ANTI-SPARK TUBING 25 M ROLLS1025U..K - POLYURETHANE ANTI-SPARK TUBING 25 M ROLLSUsed for welding applications.
1100U..K - POLYURETHANE ANTI-SPARK TUBING IN 100 M ROLLS1100U..K - POLYURETHANE ANTI-SPARK TUBING IN 100 M ROLLSUsed for welding applications.
1420U - FLEXIBLE POLYURETHANE TWIN TUBING, 25 M ROLL1420U - FLEXIBLE POLYURETHANE TWIN TUBING, 25 M ROLLCompact solution for easy assembly of a nest of tubes.
1470U - POLYURETHANE RECOIL TUBING, 2 M LONG, BSPT1470U - POLYURETHANE RECOIL TUBING, 2 M LONG, BSPTSuitable for dynamic installations.
1471U - POLYURETHANE RECOIL TUBING, 4 M LONG, BSPT1471U - POLYURETHANE RECOIL TUBING, 4 M LONG, BSPTSuitable for dynamic installations.
1472U - POLYURETHANE RECOIL TUBING, 6 M LONG, BSPT1472U - POLYURETHANE RECOIL TUBING, 6 M LONG, BSPTSuitable for dynamic installations.
1460U - POLYURETHANE RECOIL TUBING 2 M, WITHOUT CONNECTORS1460U - POLYURETHANE RECOIL TUBING 2 M, WITHOUT CONNECTORSSuitable for dynamic installations.
1461U - POLYURETHANE RECOIL TUBING 4 M, WITHOUT CONNECTORS1461U - POLYURETHANE RECOIL TUBING 4 M, WITHOUT CONNECTORSSuitable for dynamic installations.
1462U - POLYURETHANE RECOIL TUBING 6 M, WITHOUT CONNECTORS1462U - POLYURETHANE RECOIL TUBING 6 M, WITHOUT CONNECTORSSuitable for dynamic installations.
1094U - POLYURETHANE TUBING, IN 100 FOOT ROLLS1094U - POLYURETHANE TUBING, IN 100 FOOT ROLLSUsed for compact installations requiring a small bend radius and high flexibility.
Legris part number
| 1025U12R04 95 |
3109 10 13 |
| 1025U04R08 |
3109 10 17 |
| 1025U05R08 |
130910 21 |
| 1025U06R08 |
3109 12 13 |
| 1025U08R08 |
3109 12 17 |
| 1025U10R08 |
3109 12 21 |
| 1025U12R08 |
3109 14 17 |
| 1025U14R08 |
3109 14 21 |
| 1100U04R04 |
3169 04 19 |
| 1100U06R04 |
3129 04 10 |
| 1100U08R04 |
3129 04 13 |
| 1100U04R08 |
3169 06 19 |
| 1100U06R08 |
3129 06 10 |
| 1100U08R08 |
3129 06 13 |
| 1100U10R08 |
3129 08 10 |
| 1100U12R08 |
3129 08 13 |
| 1100U14R08 95 |
3129 08 17 |
| 1025P03 00 18 |
3129 10 13 |
| 1025P04 00 |
3129 10 17 |
| 1025P04 00 27 |
3129 10 21 |
| 1025P05 00 33 |
3129 12 13 |
| 1025P06 00 |
3129 12 17 |
| 1025P08 00 |
3129 12 21 |
| 1025P10 00 75 |
3129 14 17 |
| 1025P10 00 75 |
3129 14 21 |
| 1025P10 00 75 |
3193 04 19 |
| 1025P12 00 09 |
3103 04 10 |
| 1025P12 00 09 |
3103 04 13 |
| 1025P14 00 11 |
3193 06 19 |
| 1025P14 00 11 |
3103 06 10 |
| 1025P16 00 13 |
3103 06 13 |
| 1025P04 01 |
3103 08 10 |
| 1025P04 01 27 |
3103 08 13 |
| 1025P05 10 33 |
3103 08 17 |
| 1025P06 01 |
3103 10 13 |
| 1025P08 01 |
3103 10 17 |
| 1025P10 01 75 |
3103 10 21 |
| 1025P10 01 75 |
3103 10 21 |
| 1025P12 01 09 |
3103 12 13 |
| 1025P12 01 09 |
3103 12 17 |
| 1025P14 01 11 |
3108 12 21 |
| 1025P14 01 11 |
3103 14 17 |
| 1025P04 02 |
3103 14 21 |
| 1025P04 02 27 |
3131 04 19 |
| 1025P06 02 |
3121 04 10 |
| 1025P08 02 |
3121 04 13 |
| 1025P10 02 |
3121 06 10 |
| 1025P03 04 18 |
3121 06 13 |
| 1025P04 04 |
3121 08 10 |
| 1025P04 04 27 |
3121 08 13 |
| 1025P05 04 33 |
3121 08 17 |
| 1025P06 04 |
3121 10 13 |
| 1025P08 04 |
3121 10 17 |
| 1025P10 04 75 |
3121 10 21 |
| 1025P10 04 |
3121 12 17 |
| 1025P12 04 09 |
3121 12 21 |
| 1025P12 04 |
3121 14 21 |
| 1025P14 04 11 |
3106 03 00 |
| 1025P14 04 11 |
3106 04 00 |
| 1025P04 05 |
3106 06 00 |
| 1025P04 04 27 |
3106 08 00 |
| 1025P06 05 |
3106 10 00 |
| 1025P08 05 |
3106 12 00 |
|
