Parker 快速接頭和附件
Parker Quick Couplings and Accessories
Parker Quick Couplings
OEM Aftermarket Rigid Mount Connect Under Pressure Coupler (Kubota Replacement) Accepts ISO 5675 Pioneer Tips - 0312-001

Pioneer's rigid mount couplers are designed to eliminate the need for hose assemblies and break-away clamps by mounting directly to a valve or rigid tubing

0312-001 Coupler (hydraulic) 3000 psi connects with 8010 Series Pioneer male tips or other ISO 5675 compliant nipples.

The 0312-001 rigid mount coupler was developed as an aftermarket replacement for Kubota tractor OEM couplers. Pioneer's unique design permits connection while both the coupler and male tip are under pressure. These couplers can be mounted directly to a valve or rigid tubing, eliminating the need for hose assemblies and break-away clamps.

The Pioneer 0312-001 is available in packages of five. This coupler is the same product as Kubota part number 3A111-82011.

OEM Aftermarket Rigid Mount Connect Under Pressure Coupler (Kubota Replacement) Accepts ISO 5675 Pioneer Tips - 0312-001

Technical Characteristics:
- Body Size: 1/2""
- Port End: 7/8-14 UNF-2B

Markets:
- Agriculture

Features/Benefits:
- Rigid mounting directly to a valve or tubing eliminates the need for hose assemblies and breakaway clamps
- Easy push to connect /pull to disconnect under system pressure
- Enclosed outer housing prevents build up of dust and dirt
- Globally connects with Pioneer universal male tips (nipples) complying to ISO 5675 (not included in Kit)
- Each pack contains five couplings
- Pioneer part number 0312-001 is the same as Kubota part number 3A111-82011

Applications:
- Kubota Tractors with original coupling interface

Technical Specifications

OEM Aftermarket Rigid Mount Connect Under Pressure Coupler (Kubota Replacement) Accepts ISO 5675 Pioneer Tips - 0312-001 型號
