Tube Fabrication Equipment
Manual Tubing Cutter, Instrumentation Tubing
Parker's Manual Tube Cutter is a heavy duty, hand carried tool to cut instrumentation tubing. This portable Tube Cutter makes it easy to achieve clean, square cuts on 316 stainless steel, A625, A825, 6Mo and other instrumentation tubing grades.
Parker's Instrumentation Tube Cutter is a compact, easy-to-use tube cutter. This screw feed tuber cutter makes it easy to achieve clean, square cuts on 316 stainless steel, A625, A825, 6Mo and other instrumentation tubing grades. Incorporating six individual bearings and a replaceable heavy duty cutter wheel, it was specifically designed for cutting stainless steel tubing.
The cutter features a large ergonomic X-CEL knob for quicker cutting and is 100% factory tested to ensure accurate, spiral-free cutting.
Manual Tubing Cutter, Instrumentation Tubing
Markets:
- Chemical
- Petrochemical
- Power
- Research
- Pulp and Paper
- General Industry
Features/Benefits:
- Compact, Heavy Duty Design
- Designed for Instrumentation Tubing
- Replaceable cutting wheels
- Large Handle for quick turning
Applications:
- Tube Fitting Fabrication
- Tubing Systems
Technical Specifications
| Maximum Tube Outside Diameter: |
67 mm |
| Weight: |
400-680 g |
| Quantity per Box: |
1 |
| Industry Application: |
Tube Fabrication |
| Tube Outside Diameter: |
6-35 , 6-67 mm, 1/4"-1 3/8", 1/4"-2 5/8" inch |
Manual Tubing Cutter, Instrumentation Tubing 型號(hào)
| Part |
Tube O.D. (mm) |
Tube O.D. (inch) |
| PT-C |
6-35 mm |
1/4" - 1 3/8" |
| PT-CL |
6-67 mm |
1/4 - 2 5/8" |
|
