MAHLE德國瑪勒集團是世界上最大的過濾器制造商之一。作為擁有萬名以上員工的企業集團的一部分，德國MAHLE(瑪勒)過濾器公司以其精湛的工藝和廣泛的應用領域，在歐美制造業素有盛名。

德國MAHLE過濾產品:
MAHLE濾芯
MAHLE吸油過濾器
MAHLE管路過濾器
MAHLE雙聯過濾器
MAHLE回油過濾器
MAHLE旁路過濾系統及濾油車
MAHLE自清洗過濾器
MAHLE旋裝式過濾器
MAHLE油箱空氣過濾器
MAHLE污染發訊器及過濾器附件
MAHLE油品檢測儀
MAHLE空氣濾清器
MAHLE機油濾清器
MAHLE燃油濾清器
MAHLE汽車空調濾清器
MAHLE過濾介質

MAHLE德國瑪勒產品范圍：

1，吸油過濾器
2，回油過濾器
3，吸-回油過濾器
4，低壓過濾器
5，高壓過濾器
6，高壓防護過濾器
7，壓差指示器
8，油箱換氣過濾器
9，除塵過濾器濾芯，空氣過濾器，各種旋裝式（Spin-on）濾筒，自清洗過濾器， 壓縮空氣除油過濾器，雙聯過濾器，液壓、潤滑及乳化液過濾器。

1，吸油過濾器
●流量：可達315L/min
●精度：可達30um
●接口形式：管路或法蘭連接可選
●可選帶自封腳閥的形式
●適合油箱頂安裝或油箱側面安裝
●主要應用于液壓、潤滑等工程機械行業

2，回油過濾器
●流量：可達1000L/min
●壓力：1.6Mpa
●精度：可達5um
●接口形式：管路、法蘭或軟管連接
●適合油箱頂安裝，可選帶空氣過濾器，同時也可選延長管和擴散器等形式

3，吸-回油過濾器
●流量:可達600L/min
●壓力：1.0Mpa
●精度：可達12um
●接口形式：管路或法蘭連接
●適合油箱頂安裝，用于回油及閉式液壓系統，帶補油泵接口
●主要應用于工程機械行業

4，低壓過濾器
●流量：可達2000L/min
●壓力：可達10Mpa
●精度：可達5um
●接口形式：管路或法蘭連接
●可根據要求選用電子堵塞指示器或目視堵塞指示器

5，高壓過濾器
●流量:可達1000L/min
●壓力：可達60Mpa
●精度：可達5um
●接口形式：管路或法蘭連接
●可選雙向過濾器，同時也可根據用戶要求選擇電子堵塞指示器或目視堵塞指示器

6，高壓防護過濾器
●流量：可達100L/min
●壓力：可達31.5Mpa
●精度：可達60um
●接口形式：公制螺紋或管路形式連接
●用于高壓粗過濾

7，壓差指示器
●目視報警壓力：0.2...0.5Mpa
●電子報警壓力：0.12...0.5Mpa
●用于壓力和高壓過濾器的堵塞報警
●可選帶溫度校正，帶有兩個開關點
8，油箱換氣過濾器
●通風量：可達850L/min
●充油量：可達90L/min
●精度：2um
●接口形式：公制螺紋或管路連接
●用于平衡油箱壓力變化和指示液位
●可選雙單向閥、油標尺和安全型換氣過濾器

9，除塵過濾器濾芯，空氣過濾器，各種旋裝式（Spin-on）濾筒，自清洗過濾器， 壓縮空氣除油過濾器，雙聯過濾器，液壓、潤滑及乳化液過濾器。

MAHLE瑪勒濾芯

Filter elements are the heart of any effective hydraulic filtration. Made exclusively at MAHLE industrial filters in ?hringen, our unique Sm-N2 and Sm-x filter element ensure outstanding oil purity in hydraulic and lubrication systems, even in difficult applications. MAHLE hydraulic filter elements are at the forefront of modern hydraulic filtration and exceed all national and international standards. MAHLE hydraulic filter elements are made for MAHLE standard and DIN filter housings, in the dimensions of other filter manufacturers and in customer-specific designs.

MAHLE瑪勒吸油過濾器

Suction filters protect the pump of a hydraulic system from rough contamination. They are either installed in front of the pump or - especially maintenance-friendly - accessible from the outside with the clogging indicator built into the suction line.
The broad selection of system-suitable elements permits protection of the system and pump in the fine range from 10 - 25 μm with Mic quality or in the rough range with cleanable wire mesh.
Suction Filter Pi 160
Suction Filter Pi 1710, nominal size up to 480

MAHLE瑪勒管路過濾器

Pressure filters are available as full- or partial-flow filters for the pressure ranges low-pressure to 25 (60) bar, medium pressure to 210 bar, high pressure to 450 bar. The housings are of robust, flow-friendly design; the filter elements are made from a broad selection of system-suitable components adapted precisely to meet the specific requirements.
New hydraulic filters in accordance with DIN 24 550 fulfil current market demands.
An extensive accessory programme completes our offering.
Low Pressure Filter Pi 1500, operating pressure 10 (25) bar, nominal size up to 600, according to DIN 24550
Low Pressure Filter Pi 1907, operating pressure 16 bar, nominal size 400 up to 6000
Low Pressure Filter Pi 1975, operating pressure 6 bar, nominal size 50
Low Pressure Filter Pi 220, operating pressure 10 bar, nominal size up to 160
Low Pressure Filter Pi 230, operating pressure 25 (63) bar, nominal size up to 800
Low Pressure Filter Pi 2300, operating pressure 25 (40) bar, nominal size up to 2000, according to DIN 24550
Low Pressure Filter Pi 270, operating pressure 10 bar, nominal size up to 315
Medium Pressure Filter Pi 3000, operating pressure 200 (315) bar, nominal size up to 400, according to DIN 24550
Medium Pressure Filter Pi 340, operating pressure 250 bar, nominal size up to 450
Medium Pressure Filter Pi 360, operating pressure 210 (315) bar, nominal size up to 300
High Pressure Filter Pi 4000, operating pressure 400 bar, nominal size up to 400, according to DIN 24550
High Pressure Filter Pi 410, operating pressure 315 bar, nominal size 20-63
High Pressure Filter Pi 420, operating pressure 400 bar, nominal size up to 450
Low Pressure Filter Pi 150, operating pressure 10 (25) bar, nominal size up to 630

MAHLE瑪勒雙聯過濾器

Since an interruption of production to change the filter element is usually not possible in continuous processes, MAHLE offers the ideal solution with its duplex filter series. Duplex filters with standard integrated clogging indicator work trouble-free around the clock and can be easily serviced or replaced without interruption of operations or switchover breaks.
Low Pressure Duplex Filter Pi 210, operating pressure 25 (63) bar, nominal size up to 450
Low Pressure Duplex Filter Pi 2100, operating pressure 25 (63) bar, nominal size up to 40, 100, 250 according to DIN 24550
Low Pressure Duplex Filter Pi 2100, operating pressure 25 bar, nominal size up to 630 and 1000, according to DIN 24550
Low Pressure Duplex Filter Pi 231
Low Pressure Duplex Filter Pi 5075, operating pressure 16 bar, nominal size 400 up to 6000
Medium Pressure Duplex Filter Pi 370, operating pressure 200 (250) bar, nominal size up to 450
Medium Pressure Duplex Filter Pi 3700, operating pressure 200 (250) bar, nominal size up to 400, according to DIN 24550

MAHLE瑪勒回油過濾器

Return-line filters collect all the dirt that is produced in the system and rinsed out of the hydraulic system. This prevents dangerous dirt circulation arising through the tank and pump. These filters are usually installed in a space-saving way directly in the hydraulic tank and so belong to the most widely used filters for mobile machines.
Through the use of modern materials, such as plastic made of glass-fibre-reinforced polyamide as well as aluminium, MAHLE return filters are especially light. Practically all filtration degrees are possible.
Tank Top Return-line Filter Pi 500, nominal size 40 up to 100, according to DIN 24550
Tank Top Return-line Filter Pi 500, nominal size 160-1000, according to DIN 24550
Duplex Tank Top Return-line Filter Pi 510, nominal size 40 up to 1000, according to DIN 24550
Tank Top Return-line Filter Pi 530, nominal size 35 and 50

MAHLE瑪勒旁路過濾系統及濾油車

Partial-flow filters are used in stationary designs to filter large quantities of oil, which cannot be cleaned adequately or only very uneconomically with full-flow filters. Through the filter's own circuit, which is optimally adapted to it, outstanding oil cleanliness can be achieved even in very large systems. In mobile design, partial-flow filters can be used very flexibly as flushing, filling or filtering units.
Mobile Filter Unit Pi 8100, flow rates 27 and 55 l/min
External Loop Filter

MAHLE瑪勒自清洗過濾器

With their advantage of non-stop operation, MAHLE automatic filters have expanded into new areas of application in automatic purification and disposal systems. They include the regeneration of cooling lubricants, rolling, drawing, washing and similar fluids as well as the filtration of fuel and lubricants of large diesel engines in marine engineering and power plant engineering to name but a few.
Our continuous, further development of materials and manufacturing technologies guarantees economically and technically optimum products of the highest quality. MAHLE industrial filters are therefore the first choice for machine manufacturers as well as for their users.
Model: AF71L, AF71G, AF71H, AF72G, AF73G, AF73S, AF74S, AF93G, AF113G, AF133G, AF1334-parallel, AF153G, AF173G.

MAHLE瑪勒旋裝式過濾器

Spin-on cartridges are filter elements that are designed as a unit with a housing. Through their compact construction, maintenance-free handling and outstanding value for the money, spin-on cartridges are used with mobile machines and in the stationary area as suction and low-pressure filters up to 25 bar.
Equipped with highly efficient Mic and Sm-x filter inserts, MAHLE spin-on cartridges achieve the same filtration rates in the multi-pass test following ISO 16889 as do standard hydraulic filter elements.
Spin-on Cartridges, operating pressure 10/16/25 bar, nominal size up to 160

MAHLE瑪勒油箱空氣過濾器

Air breather filters are used for contamination-free air supply to tanks. A co-ordinated modular design permits flexible adaptation to the specified operating conditions. MAHLE offers a large selection of system-suitable filter elements that are corrosion- and impact-resistant and can be supplied with a variety of connection possibilities.
Air Breather Filters Pi 0101 - Pi 0185

MAHLE瑪勒污染發訊器及過濾器附件

Filter elements are used economically only when their dirt-holding capacity is completely used. The time when the filter element is exhausted must be reliably shown even after the system is shut down, and display must be as free of disturbances as possible.
Filter housings with contamination indicators fulfil this condition and also simplify maintenance. MAHLE offers a proven, unique modular system of optical and electric contamination indicators and pressure switches for almost all fluid and breather filters.
Contamination Indicators

MAHLE瑪勒油品檢測儀

The portable contamination measuring system PIC 9100 permits measurement of solid contaminants in hydraulic fluids in accordance with the standards ISO 4406 and NAS 1638.
A highly precise laser measurement system, an integrated suction pump and integrated tank permit measurements on practically all systems and machines. With the optionally available evaluation software, this equipment is an essential instrument for maintenance and service of fluid-technical systems.
Portable Contamination Measuring System Pic 9100, max. operating pressure 315 bar
