Tuthill泰悉爾快速接頭Tuthill Coupling Group 集團包括兩大生產企業：

美國Hansen快速接頭公司：總部在美國俄亥俄州,由Ford Hansen于1915年創建。世界上第一個快速拆卸接頭是由漢森制造公司發明制造的，該公司自那時以來,漢森接頭就成為了所有快速連接/拆卸接頭業的標準。在1980年，漢森制造公司成為泰悉爾公司的一個分公司。

法國Gromelle格魯梅爾：成立于1954年,也是歐洲老牌的快速接頭生產企業。 廣泛系列歐洲風格的連接器使泰悉爾連接器集團擁有在工業上最廣泛系列的產品線。

Tuthill快速接頭產品介紹： 美國漢森（Hansen）、法國格魯梅爾（Gromelle）兩大品牌的快速聯結件產品。
產品種類： -氣動接頭、氣動安全接頭、氣體接頭、注塑模接頭、液壓快速接頭、防塵蓋、轉換接頭等；
鎖定結構： -球形鎖定、螺紋鎖定、兩級安全鎖定
閥門類型： -單、雙重提升閥、自由流態、沖洗提升閥
接頭尺寸 ：1/8″至2″
壓力范圍 ：達1100bar
標準材質 ：鋼、不銹鋼、黃銅（鍍鎳）、鋼（鍍鎳鋅）、塑膠、鋁、塑料；
密封材料 ：Buna-N（丁腈橡膠）、EPDM（乙丙橡膠）、Viton(氟橡膠)、Teflon(特氟綸)和Neoprene(氯丁橡膠)和Kalrez；
螺紋 ： -N、TSO、NPT、SAE、BSPT、W、API.
標準 ：行業標準、ISO7241-1標準之A、B系列、ISO16028、ISO6150B、ISO6150C、ARO-profile

應用范圍 ： -壓縮空氣、氣體或液體、吸氣設備、焊接、醫療器械、加工設備、大流量氣動設備、煤氣灶、烤箱、移動餐車、注塑模具的冷卻和溫度調節及其它液壓應用、任何液壓設備、高流速流體輸送系統、高壓清洗機、化學處理設備、冷卻水循環系統、化學、蒸汽、真空、食品、飲料、油、氣、化工和石化行業、食品加工和制藥行業，易腐蝕工況及大流量液體應用要求、超高液壓設備、建筑業、公用工程、海上油井、震動環境，等等.

質量控制 ：Tuthill泰悉爾聯結件集團采用最高品質的原材料和零部件。產品的加工制造和裝配組合程序嚴格按照ISO9001：2000質量標準。每天的產品都作詳細記錄，并通過數據統計過程控制，不斷的監測和校正生產設備，將特定誤差降低到最小程度，以此對質量進行嚴格保證。

WA0601700 WA0601400 WV06017V0 WV06014V0 1/4" 5,7
G 1/4

WA0621700 WA0621400 WV06217V0 WV06214V0 1/4 NPT
WA0602700 WA0602400 WV06027V0 WV06024V0 3/8" 7,6
G 3/8

WA0622700 WA0622400 WV06227V0 WV06224V0 3/8 NPT
WA0603700 WA0603400 WV06037V0 WV06034V0 1/2" 10,3
G 1/2

WA0623700 WA0623400 WV06237V0 WV06234V0 1/2 NPT
WA0633700 WA0633400 WV06337V0 WV06334V0 M22 x 150
WA0604700 WA0604400 WV06047V0 WV06044V0 3/4" 14,2
G 3/4

WA0624700 WA0624400 WV06247V0 WV06244V0 3/4 NPT
WA0605700 WV06057V0 WV0605400 WV06054V0 1" 16,5
G 1

WA0625700 WA0625400 WV06257V0 WV06254V0 1 NPT
WA0635700 WA0635400 WV06357V0 WV06354V0 M33 x 150
WA0606700 WA0606400 WV06067V0 WV06064V0 1" 1/4 20,5
G 1 1/4

WA0626700 WA0626400 WV06267V0 WV06264V0 1 1/4 NPT
WA0607700 WA0607400 WV06077V0 WV06074V0 1" 1/2 25,8
G 1 1/2

WA0627700 WA0627400 WV06277V0 WV06274V0 1 1/2 NPT
WA0609700 WA0609400 WV06097V0 WV06094V0 2" 34,7
G 2

WA0629700 WA0629400 WV06297V0 WV06294V0 2 NPT
Size (in) Nominal Diameter (mm) Thread Detail Part Number Dust Plug PVC Dust Plug Aluminum
1/4" 5.3 G 1/4 WA3601700 WP3611700 WD3611700
1/4" 5.3 1/4 NPT WA3621725 WP3611700 WD3611700
3/8" 7.3 G 1/4 WA3602725BS WP3612700 WD3612700
3/8" 7.3 1/4 NPT WA3622725 WP3612700 WD3612700
3/8" 7.3 G 3/8 WA3602700 WP3612700 WD3612700
3/8" 7.3 3/8 NPT WA3622737 WP3612700 WD3612700
1/2" 10.2 G 3/8 WA3603737BS WP3613700 WD3613700
1/2" 10.2 3/8 NPT WA3623737 WP3613700 WD3613700
1/2" 10.2 G 1/2 WA3603700 WP3613700 WD3613700
1/2" 10.2 1/2 NPT WA3623750 WP3613700 WD3613700
1/2" 10.2 *8L - M14 x 1.5 WA3633708L WP3613700 WD3613700
1/2" 10.2 *10L - M16 x 1.5 WA3633710L WP3613700 WD3613700
1/2" 10.2 *12L - M18 x 1.5 WA3633712L WP3613700 WD3613700
1/2" 10.2 *15L - M22 x 1.5 WA3633715L WP3613700 WD3613700
1/2" 10.2 *15L - M22 x 1.5 WA3633715LBH WP3613700 WD3613700
3/4" 13 G 1/2 WA3604750BS WP3614700 WD3614700
3/4" 13 1/2 NPT WA3624750 WP3614700 WD3614700
3/4" 13 G 3/4 WA3604700 WP3614700 WD3614700
3/4" 13 3/4 NPT WA3624775 WP3614700 WD3614700
1" 16.9 G 3/4 WA3605775BS WP3615700 WD3615700
1" 16.9 3/4 NPT WA3625775 WP3615700 WD3615700
1" 16.9 G 1" WA3605700 WP3615700 WD3615700
1" 16.9 1" NPT WA36257100 WP3615700 WD3615700
1 1/4" 22.4 G 1 1/4" WA3606700 WP3616700 WD3616700
1 1/4" 22.4 1 1/4" NPT WA36267125 WP3616700 WD3616700
1 1/4" 22.4 G 1 1/2" WA36067150BS WP3616700 WD3616700
1 1/4" 22.4 1 1/2" NPT WA36267150 WP3616700 WD3616700
*In accordance with ISO8434-1; Light L series working pressure 250 bar max.

Plugs

Size (in) Nominal Diameter (mm) Thread Detail Part Number Dust Plug PVC Dust Plug Aluminum
1/4" 5.3 G 1/4 WA3601400 WP3611400 WD3611400
1/4" 5.3 1/4 NPT WA3621425 WP3611400 WD3611400
3/8" 7.3 G 1/4 WA3602425BS WP3612400 WD3612400
3/8" 7.3 1/4 NPT WA3622425 WP3612400 WD3612400
3/8" 7.3 G 3/8 WA3602400 WP3612400 WD3612400
3/8" 7.3 3/8 NPT WA3622437 WP3612400 WD3612400
1/2" 10.2 G 3/8 WA3603437BS WP3613400 WD3613400
1/2" 10.2 3/8 NPT WA3623437 WP3613400 WD3613400
1/2" 10.2 G 1/2 WA3603400 WP3613400 WD3613400
1/2" 10.2 1/2 NPT WA3623450 WP3613400 WD3613400
1/2" 10.2 *8L - M14 x 1.5 WA3633408L WP3613400 WD3613400
1/2" 10.2 *10L - M16 x 1.5 WA3633410L WP3613400 WD3613400
1/2" 10.2 *12L - M18 x 1.5 WA3633412L WP3613400 WD3613400
1/2" 10.2 *15L - M22 x 1.5 WA3633415L WP3613400 WD3613400
1/2" 10.2 *15L - M22 x 1.5 WA3633415LBH WP3613400 WD3613400
3/4" 13 G 1/2 WA3604450BS WP3614400 WD3614400
3/4" 13 1/2 NPT WA3624450 WP3614400 WD3614400
3/4" 13 G 3/4 WA3604400 WP3614400 WD3614400
3/4" 13 3/4 NPT WA3624475 WP3614400 WD3614400
1" 16.9 G 3/4 WA3605475BS WP3615400 WD3615400
1" 16.9 3/4 NPT WA3625475 WP3615400 WD3615400
1" 16.9 G 1" WA3605400 WP3615400 WD3615400
1" 16.9 1" NPT WA36254100 WP3615400 WD3615400
1 1/4" 22.4 G 1 1/4" WA3606400 WP3616400 WD3616400
1 1/4" 22.4 1 1/4" NPT WA36264125 WP3616400 WD3616400
1 1/4" 22.4 G 1 1/2" WA36064150BS WP3616400 WD3616400
1 1/4" 22.4 1 1/2" NPT WA36264150 WP3616400 WD3616400

Part Number End Connection Thread Detail Dust Plugs Notes
WA5651700 Male Thread 1/4-18 NPTF WA5611700 Poppet Valve
WA5652700 Male Thread 3/8-18 NPTF WA5612700 Poppet Valve
HP3SB37M Male Thread 3/8-18 NPTF WA5612700 Ball Valve
PLUGS
Part Number End Connection Thread Detail Dust Caps Notes
WA5651400 Female Thread 1/4-18 NPTF WA5611400 Poppet Valve
WA5652400 Female Thread 3/8-18 NPTF WA5612400 Poppet Valve
HP3PB37F Female Thread 3/8-18 NPTF WA5612400 Ball Valve
Part Number Nominal Diameter Thread Detail Dust Plugs
96S31 3/4" 3/4-14 NPTF SDC-96-075
96S36 1" 1-11 1/2 NPTF SDC-96-100
96S41 1 1/4" 1 1/4-11 1/2 NPTF SDC-96-125
PLUGS

Part Number Nominal Diameter Thread Detail Dust Caps
96P31 3/4" 3/4-14 NPTF PDC-96-075
96P36 1" 1-11 1/2 NPTF PDC-96-100
96P41 1 1/4" 1 1/4-11 1/2 NPTF PDC-96-125
KD0840776 KD0850776 KD0840476 KD0850476 4 1/4" 3,6
7/16 20 UNJF

KD0844716 KD0854716 KD0844416 KD0854416 12 3/4" 12,5
1 1/16 12 UNJ

KX0846756 KX0856756 KX0846456 KD0856456 16 1" 20,8
1 5/16 12 UNJ

KD0847778 KD0857778 KD0847478 KD0857416 24 1 1/2" 24,3
1 7/8 12 UNJ

Nominal Diameter Thread Detail Part Number Dust Plug
16 G 3/4 WA4604700 WA4614700
20 G 1" WA4605700 WA4615700

Plugs:

Nominal Diameter Thread Detail Part Number Dust Cap
16 G 3/4 WA4604400 WA4614400
20 G 1" WA4605400 WA4615400

Body Size Part Number Thread Size, NPTF
1/4" B4-FS-25F-2 1/4-18
3/8" B6-FS-37F-5 3/8-18
1/2" B8-FS-50F-8 1/2-14
3/4" B12-FS-75F-13 3/4-14
1" B16-FS-100F-21 1-11 1/2
1 1/2" B24-FS-150F-45 1 1/2-11 1/2
Nominal Diameter Thread Detail Part Number* Material
1/8" G 1/8 BSP RA 04000 00 Steel
1/8" G 1/8 BSP RL 04000 00 Brass
1/8" G 1/8 BSP RZ 04000 V0 Stainless Steel
1/4" G 1/4 BSP RA 04010 00 Steel
1/4" G 1/4 BSP RL 04010 00 Brass
1/4" G 1/4 BSP RZ 04010 V0 Stainless Steel
1/4" 1/4-18 NPTF RA 04210 00 Steel
3/8" G 3/8 BSP RA 04020 00 Steel
3/8" G 3/8 BSP RL 04020 00 Brass
3/8" G 3/8 BSP RZ 04020 V0 Stainless Steel
3/8" 3/8-18 NPTF RA 04220 00 Steel
1/2" G 1/2 BSP RA 04030 00 Steel

1/2" G 1/2 BSP RL 04030 00 Brass
1/2" G 1/2 BSP RZ 04030 V0 Stainless Steel
1/2" 1/2-14 NPTF RA 04230 00 Steel
3/4" G 3/4 BSP RA 04040 00 Steel
3/4" G 3/4 BSP RL 04040 00 Brass
3/4" G 3/4 BSP RZ 04040 V0 Stainless Steel

3/4" 3/4-14 NPTF RA 04240 00 Steel
1" G 1 BSP RA 04050 00 Steel
1" G 1 BSP RL 04050 00 Brass
1" G 1 BSP RZ 04050 V0 Stainless Steel
1" 1-11 1/2 NPTF RA 04250 00 Steel
1 1/4" G 1 1/4 BSP RA 04060 00 Steel
1 1/4" G 1 1/4 BSP RL 04060 00 Brass
1 1/4" G 1 1/4 BSP RZ 04060 V0 Stainless Steel
1 1/2" G 1 1/2 BSP RA 04070 Steel
1 1/2" G 1 1/2 BSP RL 04070 00 Brass
1 1/2" G 1 1/2 BSP RZ 04070 V0 Stainless Steel
2" G 2 BSP RA 04090 00 Steel
2" G 2 BSP RL 04090 00 Brass
2" G 2 BSP RZ 04090 V0 Stainless Steel
Part Number Nominal Diameter End Connection Thread Detail
UP10S25M 1/4" Male Thread 1/4-18 NPTF
UP10S37M 1/4" Male Thread 3/8-18 NPTF
UP10S25F 1/4" Female Thread 1/4-18 NPTF
UP10S37F 1/4" Female Thread 3/8-18 NPTF
PLUGS
Part Number End Connection Thread Detail
UP10P25M Male Thread 1/4-18 NPTF
UP10P37M Male Thread 3/8-18 NPTF
UP10P25F Female Thread 1/4-18 NPTF
UP10P37F Female Thread 3/8-18 NPTF
Body Size Part Number Max Working Pressure Min Burst Pressure Material
1/2" 4HFR26 7,000 psi/482 bar 28,000 psi/1,931 bar Steel
3/4" 6HFR31 5,000 psi/344 bar 18,150 psi/1,251 bar Steel
1" 8HFR36 5,000 psi/344 bar 20,000 psi/1,379 bar Steel
1" ML8HFR36 5,000 psi/344 bar 20,000 psi/1,379 bar Stainless Steel

Plug:

Body Size Part Number Max Working Pressure Min Burst Pressure Material
1/2" 4KFR26 7,000 psi/482 bar 28,000 psi/1,931 bar Steel
3/4" 6KFR31 5,000 psi/344 bar 18,150 psi/1,251 bar Steel
1" 8KFR36 5,000 psi/344 bar 20,000 psi/1,379 bar Steel
1" ML8KFR36 5,000 psi/344 bar 20,000 psi/1,379 bar Stainless Steel

HA-15000 Series

Product
Nominal Diameter
Thread Detail
Part #
Notes
Dust Plugs / Caps

Socket
1/4"
1/4-18 NPTF
HA1521100

HP1511100

Socket
1/4"
1/4-19 BSPP
HA1501100

HP1511100

Socket
3/8"
3/8-18 NPTF
HA1522100

HP1512100

Socket
3/8"
3/8-19 BSPP
HA1502100

HP1512100

Socket
1/2"
1/2-14 NPTF
HA1523100

HP1513100

Socket
1/2"
1/2-14 BSPP
HA1503100

HP1513100

Socket
1/2"
1/2-14 NPTF
HA1523600
Push to connect socket
HP1513100

Socket
1/2"
1/2-14 BSPP
HA1503600
Push to connect socket
HP1513100

Socket
3/4"
3/4-14 NPTF
HA1524100

HP1514200

Socket
3/4"
3/4-14 BSPP
HA1504100

HP1514200

Socket
1"
1-11 1/2 NPTF
HA1525100

HP1515200

Socket
1"
1-11 BSPP
HA1505100

HP1515200

Plug
1/4"
1/4-18 NPTF
HA1521200

HP1511200

Plug
1/4"
1/4-19 BSPP
HA1501200

HP1511200

Plug
3/8"
3/8-18 NPTF
HA1522200

HP1512200

Plug
3/8"
3/8-19 BSPP
HA1502200

HP1512200

Plug
1/2"
1/2-14 NPTF
HA1523200

HP1513200

Plug
1/2"
1/2-14 BSPP
HA1503200

HP1513200

Plug
3/4"
3/4-14 NPTF
HA1524200

HP1514200

Plug
3/4"
3/4-14 BSPP
HA1504200

HP1514200

Plug
1"
1-11 1/2 NPTF
HA1525200

HP1515200

Plug
1"
1-11 BSPP
HA1505200

HP1515200

Part Number Nominal Diameter Thread Detail Notes
SOCKETS
B1H11 1/8" 1/8-27 NPTF Brass; Standard
B1H11LLV146 1/8" 1/8-27 NPTF Brass
1H11 1/8" 1/8-27 NPTF Steel; Standard
1H4 1/8" 7/16-20 SAE Steel; Standard
LL1H11 1/8" 1/8-27 NPTF Stainless Steel; 303
ML1H11 1/8" 1/8-27 NPTF Stainless Steel; 316
LL1H4 1/8" 7/16-20 SAE Stainless Steel; 303
B2H16 1/4" 1/4-18 NPTF Brass; Standard
B2H16LLV146 1/4" 1/4-18 NPTF Brass; UL Listed
B2H16BS 1/4" 1/4-19 BSPP Brass; Standard
2H16 1/4" 1/4-18 NPTF Steel; Standard
2H16BS 1/4" 1/4-19 BSPP Steel; Standard
2H6 1/4" 9/16-18 SAE Steel; Standard
LL2H16 1/4" 1/4-18 NPTF Stainless Steel; 303
ML2H16 1/4" 1/4-18 NPTF Stainless Steel; 316
PP2H25F 1/4" 1/4-18 NPTF Plastic
LL2H16BS 1/4" 1/4-19 BSPP Stainless Steel; 303
ML2H16BS 1/4" 1/4-19 BSPP Stainless Steel; 316
LL2H6 1/4" 9/16-18 SAE Stainless Steel; 303
B3H21 3/8" 3/8-18 NPTF Brass; Standard
B3H21LLV146 3/8" 3/8-18 NPTF Brass
B3H21BS 3/8" 3/8-19 BSPP Brass; Standard
3H21 3/8" 3/8-18 NPTF Steel; Standard
3H21C 3/8" 3/8-18 NPTF Steel; High Impulse
3H21BS 3/8" 3/8-19 BSPP Steel; Standard
3H8 3/8" 3/4-16 SAE Steel; Standard
3H8C 3/8" 3/4-16 SAE Steel; High Impulse
LL3H21 3/8" 3/8-18 NPTF Stainless Steel; 303
ML3H21 3/8" 3/8-18 NPTF Stainless Steel; 316
LL3H21BS 3/8" 3/8-19 BSPP Stainless Steel; 303
ML3H21BS 3/8" 3/8-19 BSPP Stainless Steel; 316
LL3H8 3/8" 3/4-16 SAE Stainless Steel; 303
B4HP26 1/2" 1/2-14 NPTF Brass; Standard
B4HP26BS 1/2" 1/2-14 BSPP Brass; Standard
4HP26 1/2" 1/2-14 NPTF Steel; Standard
4HP26 1/2" 1/2-14 NPTF Steel; High Impulse
4HP26BS 1/2" 1/2-14 BSPP Steel; Standard
4HP26BS 1/2" 1/2-14 BSPP Steel; High Impulse
4HP10 1/2" 7/8-14 SAE Steel; Standard
4HP10 1/2" 7/8-14 SAE Steel; High Impulse
LL4HP26 1/2" 1/2-14 NPTF Stainless Steel; 303
ML4HP26 1/2" 1/2-14 NPTF Stainless Steel; 316
LL4HP26BS 1/2" 1/2-14 BSPP Stainless Steel; 303
ML4HP26BS 1/2" 1/2-14 BSPP Stainless Steel; 316
LL3H8 1/2" 7/8-14 SAE Stainless Steel; 303
B6HP31 3/4" 3/4-14 NPTF Brass; Standard
B6HP31BS 3/4" 3/4-14 BSPP Brass; Standard
6HP31 3/4" 3/4-14 NPTF Steel; Standard
6HP31 3/4" 3/4-14 NPTF Steel; High Impulse
6HP31BS 3/4" 3/4-14 BSPP Steel; Standard
6HP31BS 3/4" 3/4-14 BSPP Steel; High Impulse
6HP12 3/4" 1 1/16-12 SAE Steel; Standard
6HP12 3/4" 2 1/16-12 SAE Steel; High Impulse
LL6HP31 3/4" 3/4-14 NPTF Stainless Steel; 303
ML6HP31 3/4" 3/4-14 NPTF Stainless Steel; 316
LL6HP31BS 3/4" 3/4-14 BSPP Stainless Steel; 303
ML6HP31BS 3/4" 3/4-14 BSPP Stainless Steel; 316
LL6HP12 3/4" 1 1/16-12 SAE Stainless Steel; 303
B8HP36 1" 1-11 1/2 NPTF Brass; Standard
B8HP36BS 1" 1-11 BSPP Brass; Standard
8HP36 1" 1-11 1/2 NPTF Steel; Standard
8HP36 1" 1-11 1/2 NPTF Steel; High Impulse
8HP36BS 1" 1-11 BSPP Steel; Standard
8HP36BS 1" 1-11 BSPP Steel; High Impulse
8HP16 1" 1 5/16-12 SAE Steel; Standard
8HP16 1" 1 5/16-12 SAE Steel; High Impulse
LL8HP36 1" 1-11 1/2 NPTF Stainless Steel; 303
ML8HP36 1" 1-11 1/2 NPTF Stainless Steel; 316
LL8HP36BS 1" 1-11 BSPP Stainless Steel; 303
ML8HP36BS 1" 1-11 BSPP Stainless Steel; 316
LL8HP16 1" 1 5/16-12 SAE Stainless Steel; 303
PLUGS
B1K11 1/8" 1/8-27 NPTF Brass; Standard
B1K11LLV146 1/8" 1/8-27 NPTF Brass
1K11 1/8" 1/8-27 NPTF Steel; Standard
1K4 1/8" 7/16-20 SAE Steel; Standard
LL1K11 1/8" 1/8-27 NPTF Stainless Steel; 303
ML1K11 1/8" 1/8-27 NPTF Stainless Steel; 316
LL1K4 1/8" 7/16-20 SAE Stainless Steel; 303
B2K16 1/4" 1/4-18 NPTF Brass; Standard
B2K16LLV146 1/4" 1/4-18 NPTF Brass
B2K16BS 1/4" 1/4-19 BSPP Brass; Standard
2K16 1/4" 1/4-18 NPTF Steel; Standard
2K16BS 1/4" 1/4-19 BSPP Steel; Standard
2K6 1/4" 9/16-18 SAE Steel; Standard
LL2K16 1/4" 1/4-18 NPTF Stainless Steel; 303
ML2K16 1/4" 1/4-18 NPTF Stainless Steel; 316
PP2K25F 1/4" 1/4-18 NPTF Plastic
LL2K16BS 1/4" 1/4-19 BSPP Stainless Steel; 303
ML2K16BS 1/4" 1/4-19 BSPP Stainless Steel; 316
LL2K6 1/4" 9/16-18 SAE Stainless Steel; 303
B3K21 3/8" 3/8-18 NPTF Brass; Standard
B3K21LLV146 3/8" 3/8-18 NPTF Brass
B3K21BS 3/8" 3/8-19 BSPP Brass; Standard
3K21 3/8" 3/8-18 NPTF Steel; Standard
3K21C 3/8" 3/8-18 NPTF Steel; High Impulse
3K21BS 3/8" 3/8-19 BSPP Steel; Standard
3K8 3/8" 3/4-16 SAE Steel; Standard
3K8C 3/8" 3/4-16 SAE Steel; High Impulse
LL3K21 3/8" 3/8-18 NPTF Stainless Steel; 303
ML3K21 3/8" 3/8-18 NPTF Stainless Steel; 316
LL3K21BS 3/8" 3/8-19 BSPP Stainless Steel; 303
ML3K21BS 3/8" 3/8-19 BSPP Stainless Steel; 316
LL3K8 3/8" 3/4-16 SAE Stainless Steel; 303
B4KP26 1/2" 1/2-14 NPTF Brass; Standard
B4KP26BS 1/2" 1/2-14 BSPP Brass; Standard
4KP26 1/2" 1/2-14 NPTF Steel; Standard
4KP26 1/2" 1/2-14 NPTF Steel; High Impulse
4KP26BS 1/2" 1/2-14 BSPP Steel; Standard
4KP26BS 1/2" 1/2-14 BSPP Steel; High Impulse
4KP10 1/2" 7/8-14 SAE Steel; Standard
4KP10 1/2" 7/8-14 SAE Steel; High Impulse
LL4KP26 1/2" 1/2-14 NPTF Stainless Steel; 303
ML4KP26 1/2" 1/2-14 NPTF Stainless Steel; 316
LL4KP26BS 1/2" 1/2-14 BSPP Stainless Steel; 303
ML4KP26BS 1/2" 1/2-14 BSPP Stainless Steel; 316
LL4KP10 1/2" 7/8-14 SAE Stainless Steel; 303
B6KP31 3/4" 3/4-14 NPTF Brass; Standard
B6KP31BS 3/4" 3/4-14 BSPP Brass; Standard
6KP31 3/4" 3/4-14 NPTF Steel; Standard
6KP31 3/4" 3/4-14 NPTF Steel; High Impulse
6KP31BS 3/4" 3/4-14 BSPP Steel; Standard
6KP31BS 3/4" 3/4-14 BSPP Steel; High Impulse
6KP12 3/4" 1 1/16-12 SAE Steel; Standard
6KP12 3/4" 2 1/16-12 SAE Steel; High Impulse
LL6KP31 3/4" 3/4-14 NPTF Stainless Steel; 303
ML6KP31 3/4" 3/4-14 NPTF Stainless Steel; 316
LL6KP31BS 3/4" 3/4-14 BSPP Stainless Steel; 303
ML6KP31BS 3/4" 3/4-14 BSPP Stainless Steel; 316
LL6KP12 3/4" 1 1/16-12 SAE Stainless Steel; 303
B8KP36 1" 1-11 1/2 NPTF Brass; Standard
B8KP36BS 1" 1-11 BSPP Brass; Standard
8KP36 1" 1-11 1/2 NPTF Steel; Standard
8KP36 1" 1-11 1/2 NPTF Steel; High Impulse
8KP36BS 1" 1-11 BSPP Steel; Standard
8KP36BS 1" 1-11 BSPP Steel; High Impulse
8KP16 1" 1 5/16-12 SAE Steel; Standard
8KP16 1" 1 5/16-12 SAE Steel; High Impulse
LL8KP36 1" 1-11 1/2 NPTF Stainless Steel; 303
ML8KP36 1" 1-11 1/2 NPTF Stainless Steel; 316
LL8KP36BS 1" 1-11 BSPP Stainless Steel; 303
ML8KP36BS 1" 1-11 BSPP Stainless Steel; 316
LL8KP16 1" 1 5/16-12 SAE Stainless Steel; 303
Part Numbers Size DN/ND (mm)
Connection (F)

Female Socket Male Plug
Standard with Sleeve Lock
HA0500100 HA0500300 HA0500200 1/8" 3,8
G 1/8

HA0520100 HA0520300 HA0520200 1/8 NPT
HA0530100 HA0530300 HA0530200 M10 x 100
HA0501100 HA0501300 HA0501200 1/4" 5,7
G 1/4
HA0521100 HA0521300 HA0521200 1/4 NPT

HA0531100 HA0531300 HA0531200 M14 x 150
HA0502100 HA0502300 HA0502200 3/8" 7,6
G 3/8

HA0522100 HA0522300 HA0522200 3/8 NPT
HA0532100 HA0532300 HA0532200 M18 x 150
HA0503100 HA0503300 HA0503200 1/2" 10,3
G 1/2
HA0523100 HA0523300 HA0523200 1/2 NPT

HA0533100 HA0533300 HA0533200 M22 x 150
HA0504100 HA0504300 HA0504200 3/4" 14,2
G 3/4

HA0524100 HA0524300 HA0524200 3/4 NPT
HA0534100 HA0534300 HA0534200 M27 x 150
HA0505100 HA0505300 HA0505200 1 16,5
G 3/4
HA0525100 HA0525300 HA0525200 1 NPT

HA0506100 HA0506300 HA0506200 1" 1/4 20,5
G 1 1/4
HA0507100 HA0507300 HA0507200 1" 1/2 25,8 G 1 1/2
HA0509100 HA0509300 HA0509200 2" 34,7 G 2

** See catalog download in "Documents" section for brass and stainless steel part numbers.
Product Nominal Diameter Thread Detail Part Number Notes
Series 10-HK to 20-HK
Socket 1 1/4" 1 1/4-11 1/2 NPTF B10H41 Brass
Socket 1 1/4" 1 1/4-11 1/2 NPTF 10H41 Steel; Standard
Socket 1 1/4" 1 1/4-11 BSPP 10H41BS Steel; Standard
Socket 1 1/4" 1 1/4-11 1/2 NPTF LL10H41 303 Stainless Steel
Socket 1 1/4" 1 1/4-11 BSPP LL10H41BS 303 Stainless Steel
Socket 1 1/2" 1 1/4-11 1/2 NPTF B12H41 Brass
Socket 1 1/2" 1 1/4-11 BSPP B12H41BS Brass
Socket 1 1/2" 1 1/2-11 1/2 NPTF B12H46 Brass
Socket 1 1/2" 1 1/2-11 BSPP B12H46BS Brass
Socket 1 1/2" 1 1/4-11 1/2 NPTF 12H41 Steel; Standard
Socket 1 1/2" 1 1/4-11 1/2 NPTF 12H41C Steel; High Impulse
Socket 1 1/2" 1 1/4-11 BSPP 12H41BS Steel; Standard
Socket 1 1/2" 1 1/2-11 1/2 NPTF 12H46 Steel; Standard
Socket 1 1/2" 1 1/2-11 1/2 NPTF 12H46C Steel; High Impulse
Socket 1 1/2" 1 1/2-11 BSPP 12H46BS Steel; Standard
Socket 1 1/2" 1 1/4-11 1/2 NPTF LL12H41 303 Stainless Steel
Socket 1 1/2" 1 1/4-11 BSPP LL12H41BS 303 Stainless Steel
Socket 1 1/2" 1 1/2-11 1/2 NPTF LL12H46 303 Stainless Steel
Socket 1 1/2" 1 1/2-11 BSPP LL12H46BS 303 Stainless Steel
Socket 2 1/2" 2-11 1/2 NPTF B20H51 Brass
Socket 2 1/2" 2-11 BSPP B20H51BS Brass
Socket 2 1/2" 2 1/2-8 NPTF B20H56 Brass
Socket 2 1/2" 2 1/2-11 BSPP B20H56BS Brass
Socket 2 1/2" 3-8 NPTF B20H61 Brass
Socket 2 1/2" 3-11 BSPP B20H61BS Brass
Socket 2 1/2" 2-11 1/2 NPTF 20H51 Steel; Standard
Socket 2 1/2" 2-11 1/2 NPTF 20H51C Steel; High Impulse
Socket 2 1/2" 2-11 BSPP 20H51BS Steel; Standard
Socket 2 1/2" 2 1/2-8 NPTF 20H56 Steel; Standard
Socket 2 1/2" 2 1/2-8 NPTF 20H56C Steel; High Impulse
Socket 2 1/2" 2 1/2-11 BSPP 20H56BS Steel; Standard
Socket 2 1/2" 3-8 NPTF 20H61 Steel; Standard
Socket 2 1/2" 3-8 NPTF 20H61C Steel; High Impulse
Socket 2 1/2" 3-11 BSPP 20H61BS Steel; Standard
Socket 2 1/2" 2-11 1/2 NPTF LL20H51 303 Stainless Steel
Socket 2 1/2" 2-11 BSPP LL20H51BS 303 Stainless Steel
Socket 2 1/2" 2 1/2-8 NPTF LL20H56 303 Stainless Steel
Socket 2 1/2" 2 1/2-11 BSPP LL20H56BS 303 Stainless Steel
Socket 2 1/2" 3-8 NPTF LL20H61 303 Stainless Steel
Socket 2 1/2" 3-11 BSPP LL20H61BS 303 Stainless Steel
Plug 1 1/4" 1 1/4-11 1/2 NPTF B10K41 Brass
Plug 1 1/4" 1 1/4-11 1/2 NPTF 10K41 Steel; Standard
Plug 1 1/4" 1 1/4-11 BSPP 10K41BS Steel; Standard
Plug 1 1/4" 1 1/4-11 1/2 NPTF LL10K41 303 Stainless Steel
Plug 1 1/4" 1 1/4-11 BSPP LL10K41BS 303 Stainless Steel
Plug 1 1/2" 1 1/4-11 1/2 NPTF B12K41 Brass
Plug 1 1/2" 1 1/4-11 BSPP B12K41BS Brass
Plug 1 1/2" 1 1/2-11 1/2 NPTF B12K46 Brass
Plug 1 1/2" 1 1/2-11 BSPP B12K46BS Brass
Plug 1 1/2" 1 1/4-11 1/2 NPTF 12K41 Steel; Standard
Plug 1 1/2" 1 1/4-11 1/2 NPTF 12K41C Steel; High Impulse
Plug 1 1/2" 1 1/4-11 BSPP 12K41BS Steel; Standard
Plug 1 1/2" 1 1/2-11 1/2 NPTF 12K46 Steel; Standard
Plug 1 1/2" 1 1/2-11 1/2 NPTF 12K46C Steel; High Impulse
Plug 1 1/2" 1 1/2-11 BSPP 12K46BS Steel; Standard
Plug 1 1/2" 1 1/4-11 1/2 NPTF LL12K41 303 Stainless Steel
Plug 1 1/2" 1 1/4-11 BSPP LL12K41BS 303 Stainless Steel
Plug 1 1/2" 1 1/2-11 1/2 NPTF LL12K46 303 Stainless Steel
Plug 1 1/2" 1 1/2-11 BSPP LL12K46BS 303 Stainless Steel
Plug 2 1/2" 2-11 1/2 NPTF B20K51 Brass
Plug 2 1/2" 2-11 BSPP B20K51BS Brass
Plug 2 1/2" 2 1/2-8 NPTF B20K56 Brass
Plug 2 1/2" 2 1/2-11 BSPP B20K56BS Brass
Plug 2 1/2" 3-8 NPTF B20K61 Brass
Plug 2 1/2" 3-11 BSPP B20K61BS Brass
Plug 2 1/2" 2-11 1/2 NPTF 20K51 Steel; Standard
Plug 2 1/2" 2-11 1/2 NPTF 20K51C Steel; High Impulse
Plug 2 1/2" 2-11 BSPP 20K51BS Steel; Standard
Plug 2 1/2" 2 1/2-8 NPTF 20K56 Steel; Standard
Plug 2 1/2" 2 1/2-8 NPTF 20K56C Steel; High Impulse
Plug 2 1/2" 2 1/2-11 BSPP 20K56BS Steel; Standard
Plug 2 1/2" 3-8 NPTF 20K61 Steel; Standard
Plug 2 1/2" 3-8 NPTF 20K61C Steel; High Impulse
Plug 2 1/2" 3-11 BSPP 20K61BS Steel; Standard
Plug 2 1/2" 2-11 1/2 NPTF LL20K51 303 Stainless Steel
Plug 2 1/2" 2-11 BSPP LL20K51BS 303 Stainless Steel
Plug 2 1/2" 2 1/2-8 NPTF LL20K56 303 Stainless Steel
Plug 2 1/2" 2 1/2-11 BSPP LL20K56BS 303 Stainless Steel
Plug 2 1/2" 3-8 NPTF LL20K61 303 Stainless Steel
Plug 2 1/2" 3-11 BSPP LL20K61BS 303 Stainless Steel

Part Numbers and Dimensions

Part Numbers Size
DN/ND (mm)
Connection (F)

Sockets Plugs Dust Plugs Dust Caps
HA5502100 HA5502200 HD0512100 HD0512200 3/8"
5,9
G 3/8

HA5503100 HA5503200 HD0513100 HD0513200 1/2"
7
G 1/2

HP1513100 HP1513200

Socket
1/4"
Male Thread
1/8-27 NPTF
2HIG10



Socket
1/4"
Male Thread
1/4-18 NPTF
2HIG15



Socket
1/4"
Male Thread
3/8-18 NPTF
2HIG20



Socket
1/4"
Male Thread
7/16-20
2HIG720
1/4" SAE Flare


Socket
1/4"
Male Thread
7/16-20
2HIGLLRA720
1/4" SAE Flare; Right-angle connection


Socket
1/4"
Female Thread
1/8-27 NPTF
2HIG11



Socket
1/4"
Female Thread
1/4-18 NPTF
2HIG16



Plug

Male Thread
1/4-18 NPTF
2KIGF15

P-PDC-2-HK

Plug

Male Thread
3/8-18 NPTF
2KIGF20

P-PDC-2-HK

Plug

Female Thread
2-KIG-F16
2HIG11

P-PDC-2-HK

Plug

Female Thread
2-KIG-F720
2HIG16
1/4" SAE Flare
P-PDC-2-HK

Acero
G 1/8
LA0700100
HD0510100

Acero
G 1/4
LA0701100
HD0511100

Acero
G 3/8
LA0702100
HD0512100

Acero
G 1/2
LA0703100
HD0513100

Acero
G 3/4
LA0704100
HD0514100

Acero
G 1
LA0705100
HD0515100

Acero
G 1 1/4
LA0706100
HD0516100

Acero
G 1 1/2
LA0707100
HD0517100

Acero
G 2
LA0709100
HD0519100

Latón
G 1/8
LL0700100
HD0510100

Latón
G 1/4
LL0701100
HD0511100

Latón
G 3/8
LL0702100
HD0512100

Latón
G 1/2
LL0703100
HD0513100

Latón
G 3/4
LL0704100
HD0514100

Latón
G 1
LL0705100
HD0515100

Latón
G 1 1/4
LL0706100
HD0516100

Latón
G 1 1/2
LL0707100
HD0517100


Latón
G 2
LL0709100
HD0519100


Acero inoxidable
G 1/8
LZ07001V0
HD0510100

Acero inoxidable
G 1/4
LZ07011V0
HD0511100


Acero inoxidable
G 3/8
LZ07021V0
HD0512100


Acero inoxidable
G 1/2
LZ07031V0
HD0513100


Acero inoxidable
G 3/4
LZ07041V0
HD0514100


Acero inoxidable
G 1
LZ07051V0
HD0515100


Acero inoxidable
G 1 1/4
LZ07061V0
HD0516100

Acero inoxidable
G 1 1/2
LZ07071V0
HD0517100


Acero inoxidable
G 2
LZ07091V0
HD0519100

Plugs:

Material
Detalle de rosca
Número de pieza
Casquillo/Plug guardapolvos

Acero
G 1/8
LA0700200
HD0510200

Acero
G 1/4
LA0701200
HD0511200

Acero
G 3/8
LA0702200
HD0512200

Acero
G 1/2
LA0703200
HD0513200

Acero
G 3/4
LA0704200
HD0514200

Acero
G 1
LA0705200
HD0515200

Acero
G 1 1/4
LA0706200
HD0516200

Acero
G 1 1/2
LA0707200
HD0517200

Acero
G 2
LA0709200
HD0519200

Latón
G 1/8
LL0700200
HD0510200

Latón
G 1/4
LL0701200
HD0511200

Latón
G 3/8
LL0702200
HD0512200

Latón
G 1/2
LL0703200
HD0513200

Latón
G 3/4
LL0704200
HD0514200

Latón
G 1
LL0705200
HD0515200

Latón
G 1 1/4
LL0706200
HD0516200

Latón
G 1 1/2
LL070700
HD0517200


Latón
G 2
LL0709200
HD0519200


Acero inoxidable
G 1/8
LZ0700200
HD0510200

Acero inoxidable
G 1/4
LZ0701200
HD0511200


Acero inoxidable
G 3/8
LZ0702200
HD0512200


Acero inoxidable
G 1/2
LZ0703200
HD0513200


Acero inoxidable
G 3/4
LZ0704200
HD0514200


Acero inoxidable
G 1
LZ0705200
HD0515200


Acero inoxidable
G 1 1/4
LZ0706200
HD0516200

Acero inoxidable
G 1 1/2
LZ0707200
HD0517200


Acero inoxidable
G 2
LZ0709200
HD0519200
