美國FPP METERS橢圓齒輪流量計
FPP METERS公司成立于1987年，是美國享譽盛名TUTHILL TRansfer Systems(簡稱TTS)的一個業務單元，工廠位于美國新奧爾良的路易斯安那州，占地面積20,000平方英尺，公司早期屬于ROCKWELL公司擁有，在1996時由TTS收購過來，F(xiàn)PP METERS公司致力于制造性能價格比優異，并被廣泛地應用于如石油，通用工業，商貿零售業及市政工程服務領域等多種領域的流量計。
計量原理：
橢圓齒輪的計量原理是古老的的正排量設計之一，但在FPPMETERS工程師手里，卻誕生了使用新材料和工藝，具有現代概念的面向21世紀的全新的概念的橢圓齒輪流量計。在保持測量大范圍粘度和流量的能力的同時，技術的革新又產生了更緊湊的設計和卓越的性能。FPPMETERS從而能夠自豪地為客戶提供獲得美國的新一代橢圓齒輪技術。
精確性。的設計可以符合絕大多數國家的度量衡標準，無論是測量高粘度還是低粘度的液體，一旦安裝完畢，安靜，精確的運行，易于維護的特點，幾乎可以使您忘記了還有這么個流量計在為您日復一日的工作。
簡單性。FPPMETERS的流量計只有兩個轉動的部件在測量腔體中，所以輕易不會發生當機。如果有必要，經濟的維修配件，無需從工作地點拆除的特點，使得流量計可以更加經濟的擁有和操作。
經濟性－低成本和高精度。FPPMETERS的流量計是低成本高精度的，易于承擔的初期成本，長壽命的設計，以及易于維護的特點使得FPPMETERS流量計成為廣大客戶明智和自然而然的選擇。
應用領域。FPPMETERS流量計有一系列的流量范圍，不同的材質和配置可用于：醋酸鹽，酒精，動力燃油，航空燃油，腐蝕劑，玉米糖漿，柴油，化肥，燃料油，汽油，乙二醇，除草劑，蜂蜜，乳膠，液體糖精，煤油，油漆，殺蟲劑，可塑劑，油墨，樹脂，溶劑，蔬菜油，水，也可作為國家計量部門的標準表使用。
應用方式。罐裝，批量和混合裝，大批量裝載，燃料消耗，高速加油，存量控制，流量控制，燃料入庫，坦克箱和運輸服務。
 |
 |
FPP 電子式流量計-批量控制,線性化,標定, 脈沖模擬信號轉換輸出, 各種補償量,可連接電腦，PLC等,進行集成化控制等,過濾器,排空閥以及空氣截止閥配合使用,提高計量精度和工作的穩定性
|
FPP機械式流量計-兩段式批量控制,也可有電子信號輸出. 過濾器,排空閥以及空氣截止閥配合使用,提高計量精度和工作的穩定性 |
FPP METERS橢圓齒輪流量計
|
TM Series流量計
尺寸: 1/4", 3/8", 1/2", 3/4"
Mini flow meters with flow rates to 0.03 gpm or less. Provide accurate records in additive injection, fuel consumption, jug filling and many other low flow systems
PDF: TM02D, TM03A, TM04A, TM06A |
|
TN Series流量計
尺寸: 1", 1-1/2"
With inventory control accuracy, these meter are available for transfer, blending, batching & dispensing service. Meters can be assembled with either mechanical & electronic register.
PDF: brochure |
|
TS Custody Transfer Certified Series流量計
Sizes: 1", 1-1/2", 2", 3"
TS Series flow meters are approved by NTEP (formerly NIST) for Weights & Measures service in the US. Selected models are approved by similar authorities in Australia, Canada and teh EEC.
PDF: TS10A, TS15A, TS20A, TS30A (available in stainless steel) |
|
TS Industrial Series流量計
尺寸: 1", 1-1/2", 2", 3"
Industrial flow meters are available with either mechanical or electronic registers, and can be assembled to suit the most demanding operational requirments. Electronic assemblies are gland-less, and can have the display either mounted or remote.
PDF: TS10A, TS15A, TS20A, TS30A (available in stainless steel) |
|
Accessories |
|
Electronic Large Numerical Counter (ELNC)
數字表
Featuring 6 digits of reset total and 8 digits of non-reset total, the ELNC is a battery powered indicator capable of accepting DC pulse and switch closure inputs. It is also field programmable and can be used with all FPP meters. Programmable in gallons, liters, barrelad and most other engineering units.
PDF: brochure |
|
Battery Powered Scaling Counter
數字表
CC56 economical electronic register is available in either NEMA 4X or NEMA 7/4 enclosures (or NEMA 3R, TM series meters only). Other registers with higher levels of functionality are available
PDF: CC56 |
|
Signal Conditioners
信號調節器
Tuthill currently offer three signal conditioners that will assist you with scaling, and amplifying, linearizing, splitting, asolating and vonverting your signals to analog
PDF: PAC, PIA, SCL |
|
Batching Systems
Batching function is available both in mechanical and electronic flow meter assemblies. the mechanical version is available in TS series only. The electronic version can be combined with the TM, TS or TN series meters.
PDF: PDB180, PDB480, EMR3
|
|
Pulsers
TM & TS series meters are available with a choice of 3 different pulsers.
Hall Effect (single channel) is standard, and requires external DC power
Reed Switch (single channel) is optional, used only when battery powered registers
Hall Effect (dual channel = Quadrature) is optional for use with higher level electronics
|
|
Control Valves
For use with mechanical preset counters, we offer mechanical piston valves with a linkage to attach to the preset.
For use with electronic registers & batch controllers we offer several different types of solenoid valves. |
|
Air Elimination
FPP Air Eliminators function on a gravity principle, and are normally installed on top of the FPP Strainer. In systems with little or no back pressure, either a back pressure valve or an air check valve may be required to enhance the efficiency of the air eliminator.
On higher viscosity liquids such as diesel fuel, the air may not have enough time to rise during passage of a standard strainer. For use on higher viscosity liquids, a high capacity strainer with greater holding capacity is available. Please consult with your distributor to determine whether a high capacity strainer is required.
For LPG service, a vapor eliminator with pressure relief valve is used, in conjunction with a differential pressure check valve on flow meter outlet. |
|
Strainers
To ensure error and damage free operation of your flow meter, it is recommended that a strainer be installed "upstream" to avoid ingestion of particulates.
PDF: |
FPP橢圓齒輪流量計主要特點 :
精確性: 的設計可以符合絕大多數國家的度量衡標準，無論是測量高粘度還是低粘度的液體，一旦安裝完畢，安靜，精確的運行，易于維護的特點，幾乎可以使您忘記了還有這么個流量計在為您日復一日的工作。
簡單性: FPPMETERS的流量計只有兩個轉動的部件在測量腔體中，所以輕易不會發生當機。如果有必要，經濟的維修配件，無需從工作地點拆除的特點，使得流量計可以更加經濟的擁有和操作。
經濟性: 低成本和高精度。FPPMETERS的流量計是低成本高精度的，易于承擔的初期成本，長壽命的設計，以及易于維護的特點使得FPPMETERS流量計成為廣大客戶明智和自然而然的選擇。
應用領域: FPPMETERS流量計有一系列的流量范圍，不同的材質和配置可用于：醋酸鹽，酒精，動力燃油，航空燃油，腐蝕劑，玉米糖漿，柴油，化肥，燃料油，汽油，乙二醇，除草劑，蜂蜜，乳膠，液體糖精，煤油，油漆，殺蟲劑，可塑劑，油墨，樹脂，溶劑，蔬菜油，水，也可作為國家計量部門的標準表使用。
應用方式: 罐裝，批量和混合裝，大批量裝載，燃料消耗，高速加油，存量控制，流量控制，燃料入庫，坦克箱和運輸服務。
FPP流量計的流量比為10:1
材質有316不銹鋼，303不銹鋼和鋁合金
壓力等級 28, 103, 172 公斤
溫度范圍: 150攝氏度
FPP Flow Meters TM Series Liquid Flow Meters
TM03A, 3/8" Anodized Aluminum, Nominal 0.3-3 GPM (1.1-11.4 lpm)
TM04A, Anodized Aluminum, Nominal 1-10 GPM (3.8-38 lpm)
TM06A , Anodized Aluminum, Nominal 2-20 GPM (7.6-76 lpm)
TM06C, 303 Stainless Steel, Nominal 2-20 GPM (7.6-76 lpm)
TM02D , 316 Stainless Steel, Nominal 0.03-0.3 GPM (0.1-1.1 lpm)
TM03D, 3/8" 316 Stainless Steel, Nominal 0.3-3 GPM (1.1-11.4 lpm)
TM04D, 316 Stainless Steel, Nominal 1-10 GPM (3.8-38 lpm)
TM06D, 316 Stainless Steel, Nominal 2-20 GPM (7.6-76 lpm)
FPP Flow Meters > TN Series Liquid Flow Meters > TN700 Series
TN740A 1" or 1, Anodized Aluminum, 400 PSI, Nominal 40 GPM (150 lpm)
1" Anodized Aluminum, 1000 PSI, Nominal 40 GPM (150 lpm) TN Series
TN760A 1, Anodized Aluminum, 400 PSI, Nominal 60 GPM (230 lpm)
TN840A 1" or 1 Anodized Aluminum, 400 PSI, Nominal 40 GPM (150 lpm) TN Series
TN860A 1 Anodized Aluminum, 400 PSI, Nominal 60 GPM (230 lpm)
TN620
Flow Meters TS Series Liquid Flow Meters
TS10A 1" Anodized Aluminum, Nominal 8-40 GPM (30-150 lpm)
TS15A 1 Anodized Aluminum, Nominal 12-60 GPM (45-230 lpm)
TS20A 2" Anodized Aluminum, Nominal 20-150 GPM (75-570 lpm)
TS30A 3" Anodized Aluminum, Nominal 40-200 GPM (150-760 lpm)
TS10C 1" 303 Stainless Steel, Nominal 8-40 GPM (30-150 lpm)
TS10D 1" 316 Stainless Steel, Nominal 8-40 GPM (30-150 lpm)
TS15C 1 316 Stainless Steel, Nominal 12-60 GPM (45-230 lpm)
TS20C 2" 316 Stainless Steel, Nominal 20-100 GPM (75-380 lpm)
TS30C 3" 316 Stainless Steel, Nominal 40-200 GPM (150-760 lpm)
FPP MetersFPP Flow Meters FPP Oval Gear Flow Meter FPP Meters: Liquid Glow Meters @ Tuthill.com FPP Flow Meters Liquid Flow Meters TM03A TM04A TM06A TM06C TM02D TM03D TM04D TM06D TN740A TN760A TN840A TN860A TN620 TS10A TS15A TS20A TS30A TS10C TS10D TS15C TS20C TS30C
TUTHILL PA1-60PA2-80PA2-100SD1202SD1202LSD1202AFR1210CFR4210D806CL807CL807CL1901L901L1.5820
|
|
|
|
規格 |
型號 |
流量范圍 |
1/4”
|
TM02 |
0.1-1.1LPM |
3/8” |
TM03 |
1.1-11.4LPM |
1/2” |
TM04 |
3.8-38LPM |
3/4”
|
TM06 |
7.6-76LPM |
1” |
TS10 |
15-150LPM |
11/2” |
TS15 |
23-230LPM |
2”
|
TS20C |
38-380LPM |
2” |
TS20A |
38-570LPM |
3-4” |
TS30 |
76-1000LPM |
|
