E2X & E2F 氫氣防爆壓力傳感器 E2X & E2F Explosion-Proof Pressure Transducer
CVD 薄膜傳感器
當需要防爆或防爆危險認證時 ，Ashcroft E2X 和 E2F 壓力傳感器滿足廣泛的壓力傳感要求。 使用 Ashcroft 經驗證的 CVD 薄膜傳感器技術，可提供根據 Ashcroft 的 TruAccuracy 終點標準制造的可靠且可重復的傳感器。 Ashcroft 的直接 TruAccuracy 標準消除了從統計得出的準確度規格中的混淆，并避免了在安裝時進行用戶校準的需要。 這使得 E2X 和 E2F 成為要求苛刻的危險工業和過程應用的理想選擇。
The Ashcroft ? E2X and E2F pressure transducers fulfills a wide spectrum of pressure sensing requirements when explosion or flameproof hazardous approvals are required. Using Ashcroft's proven CVD thin film sensor technology provides a reliable and repeatable sensor manufactured to Ashcroft's TruAccuracy terminal point standard. The Ashcroft's straight forward TruAccuracy standard eliminates confusion from statistically derived accuracy specifications and avoids the need for user calibration at the time of installation. This makes the E2X and E2F ideal for demanding hazardous industrial and process applications.
數據表：
數據表 – E2X-E2F 防爆壓力傳感器
數據表 – E2X-E2F 防爆壓力傳感器（氫氣應用）
主要特征：
- 使用 Ashcroft 經過驗證的 CVD 薄膜技術
- 提供 +/-0.25%、+/- 0.50% 或 +/-1.0% 的量程精度
- 標準范圍從真空到 20,000 psi 和 0 到 500 psia（可定制范圍）
- 堅固的 316 不銹鋼外殼
- 隔膜可提供 17-4 PH、316L 不銹鋼或 A286 材質
- E2X – FM、ATEX 和 IECEx 雙重隔爆/本質安全認證
- E2F – FM、ATEX 和 IECEx 隔爆認證
- FM 非易燃批準
- 4-20mA 或多個電壓輸出可用
- 外部磁偏移和跨度調整
- CE認證
- 符合 RoHS
應用：
工業和 OEM 應用：
油田設備
過程應用：
上游石油和天然氣生產
天然氣壓縮和傳輸控制
替代能源
發動機監控
過程和氣動傳感
氫應用 Hydrogen applications
參考溫度
21°C ±2°C (70°F ±3°F)
精度
±0.25%、±0.5%、±1.0% 量程終點法包括：滯后、不可重復性、零偏移和量程設置誤差
參考條件下的 穩定性 ≤±0.25% 跨度/年
耐用性
>1000 萬次循環
壓力范圍
真空至 20,000 psig，0 至 500 psi 絕對壓力
氣密等級
IP66
IP67
IP69K（咨詢工廠）
輸出
0-10 Vdc（3 線）
0-5 Vdc（3 線）
0.1-10 Vdc（3 線）
0.1-5 Vdc（3 線）
0.5-4.5 Vdc（3 線）
1-11 Vdc（3 線）
1 -5 Vdc（3 線）
1-6 Vdc（3 線）
20-4 mA（2 線）
4-20 mA（2 線）
接液材料
隔膜：17-4PH 不銹鋼、316L 不銹鋼、316L 不銹鋼液體隔離、A286
過程連接：316L 不銹鋼
非接液材料
外殼：316L 不銹鋼
過程連接
1/4 NPT 外螺紋
1/8 NPT 外螺紋
NPT 內螺紋
NPT 外螺紋
-14 NPT 內螺紋
NPT 內螺紋
VCR 密封套，帶 916-18 內螺紋旋轉螺母
VCR 密封套，帶 916-18 外螺紋旋轉螺母
-18 NPT 內螺紋
18 -27 NPT 內螺紋
716-20 UNF-2B SAE J1926
716-20 UNJF-2A SAE 外螺紋（SAE J1926 O 型圈凸臺密封）
716-20 UNJF- 3A 37° 擴口 (SAE AS4395)
916-18 UNF-2B 內螺紋
G1/4 A-MALE（螺栓端 DIN 3852-E G）
G B 外螺紋 (EN837-1)
G B-外螺紋 (EN837-1)
衛生密封件 1.5 Tri-Clamp
衛生密封 件 2 Tri-Clamp
抗沖擊和振動
10g RMS 20-20,000Hz 振動
80g, 6ms 半正弦沖擊
E2X & E2F Explosion-Proof Pressure Transducer
The Ashcroft E2X and E2F pressure transducers fulfills a wide spectrum of pressure sensing requirements when explosion or flameproof hazardous approvals are required. Using Ashcroft’s proven CVD thin film sensor technology provides a reliable and repeatable sensor manufactured to Ashcroft’s TruAccuracy terminal point standard. The Ashcroft’s straight forward TruAccuracy standard eliminates confusion from statistically derived accuracy specifications and avoids the need for user calibration at the time of installation. This makes the E2X and E2F ideal for demanding hazardous industrial and process applications.
Key Features:
- Uses Ashcroft's proven CVD thin film technology
- +/-0.25%, +/- 0.50% or +/-1.0% of span accuracy available
- Standard ranges from vacuum to 20,000 psi and 0 to 500 psia (custom ranges available)
- Rugged 316 stainless steel Housing
- Diaphragm available in 17-4 PH, 316L stainless steel or A286
- E2X – FM, ATEX and IECEx dual Flameproof/Intrinsically Safe approval
- E2F – FM, ATEX and IECEx flameproof approval
- FM non-incendive approval
- 4-20mA or multiple Voltage outputs available
- External magnetic offset and span adjustment
- CE approved
- RoHS compliant
Applications:
Industrial and OEM Applications:
Oil Field Equipment
Process Applications:
Upstream Oil and Gas Production
Natural Gas Compression and Transfer Control
Alternative Energy
Engine Monitoring
Process & Pneumatic Sensing
Hydrogen applications
Reference Temperature
21°C ±2°C (70°F ±3°F)
Accuracy
±0.25%, ±0.5%, ±1.0% of span Terminal Point Method includes: hysteresis, non-repeatability, zero offset and span setting errors
Stability
≤±0.25% span/year at reference conditions
Durability
>10 million cycles
Pressure Ranges
Vacuum to 20,000 psig, 0 to 500 psi absolute
Ingress Rating
IP66
IP67
IP69K (consult factory)
Outputs
0-10 Vdc (3 Wire)
0-5 Vdc (3 Wire)
0.1-10 Vdc (3 Wire)
0.1-5 Vdc (3 Wire)
0.5-4.5 Vdc (3 Wire)
1-11 Vdc (3 Wire)
1-5 Vdc (3 Wire)
1-6 Vdc (3 Wire)
20-4 mA (2 Wire)
4-20 mA (2 Wire)
Wetted Material
Diaphragm: 17-4PH Stainless steel, 316L Stainless steel, 316L Stainless steel liquid isolated, A286
Process Connection: 316L Stainless Steel
Non-Wetted Materials
Housing: 316L Stainless steel
Process Connection
1/4 NPT Male
1/8 NPT Male
NPT Female
NPT Male
-14 NPT Female
NPT Female
VCR gland with 916-18 Female Swivel Nut
VCR gland with 916-18 Male Swivel Nut
-18 NPT Female
18 -27 NPT Female
716-20 UNF-2B SAE J1926
716-20 UNJF-2A SAE Male (SAE J1926 O-Ring Boss seal)
716-20 UNJF-3A 37° Flare (SAE AS4395)
916-18 UNF-2B Female
G1/4 A-MALE (stud end DIN 3852-E G)
G B Male (EN837-1)
G B-Male (EN837-1)
Sanitary Seal 1.5 Tri-Clamp
Sanitary Seal 2 Tri-Clamp
Shock & Vibration Resistance
10g RMS 20-20,000Hz Vibration
80g, 6ms Haversine Shock
