      Harnessflex Type JPH - High Temperature Hinged Joiner




      Harnessflex TempGuard hinged fittings


      One-piece joiner and elbow hinged fittings allow a variety of conduit size variations. These fittings are designed to snap together over all types of slit and unslit Harnessflex conduit, maintaining maximum conduit bore. Can be used as an in-line reducer as well as an enlarger. Full TempGuard system protection is achieved using these fittings with HTC conduit.




      Harnessflex Download Type JPH - High Temperature Hinged Joiner datasheet















      Temperature Range






      Minimum


      -40oC






      Permanent Max


      +160oC






      Long term max (30,000 hrs)


      +185oC






      Short term max (3,000 hrs)


      +200oC








      • One-piece external design for unrestricted bore and quick assembly with no tools.


        •

      • High pull-off strength - conduit corrugations sit tightly into joiner junctions.


        •

      • Conduit size labels - each junction indicates nominal conduit size to aid installation


        •

      • High Temperature Polyamide (Nylon) - Low Smoke & Halogen Free


        •

      • IP40 rated


        •

      • High UV resistance
        •











      Conformity







      • CE Mark to the low voltage directive


        •

      • RoHS Compliant to 2011/65/EU


        •

      • Conforms with end of life vehicle directive (ELV) EU200/53/EC
        •

      • UL94 V2 / UL94 RTI 150 (Elec)
        •













      Harnessflex Download Type JPH - High Temperature Hinged Joiner datasheet Parts List





                  Conduit Size (NC)
            Conduit Size (NW)




            Part no
            A
            B
            A
            B




            JPH1212
            12
            12
            10
            10




            JPH1612
            16
            12
            13
            10




            JPH1208*
            12
            08
            10
            7.5




            JPH1616*
            16
            16
            13
            13




            JPH2008*
            20
            08
            17
            7.5




            JPH2016*
            20
            16
            17
            13




            JPH2020*
            20
            20
            17
            17










      *Made to order - Part numbers listed are available to order but not stocked items, and would therefore be subject to manufacturing leadtime
